Why Arista with Hamburgnet?
As an Arista Networks partner in Europe, we offer you our technical expertise and our certified ACE-L3/L5 technicians offer you advice and support for the planning and installation of your network. Rely on us to acquire Arista parts with the highest level of expertise!
If you already know Cisco, you are good to go. Learn a few new commands in a day. Nothing proprietary, everything open standard.
Direct contact with an Arista TAC engineer within one minute. No first/second level support like with other manufacturers.
Arista platforms integrate with almost all firewall, security, big data, automation, NLB, HCI, storage, etc. vendors.
A single operating system (EOS) for all platforms makes it easier to train, manage, update and expand the environment.
Unmatched transparency with comprehensive status streaming. Open APIs for easy integration with your own or third-party tools.
Fewer licenses (3 or fewer SKUs) and significantly lower energy and cost consumption than switches from other competitors.
What we offer you
- The best possible and in-depth consulting → Our experts have over 16 years of know-how in this field
- Optimal pricing thanks to our Arista partner status → We offer better conditions than many competitors
- Fast and secure delivery of the hardware → Pre-configured, tested and insured
- Certified ACE-L3/L5 technicians → Trained and certified technical staff, always ready to support you personally
Do you have any questions?
Our team of experts will be happy to help you personally with any technical questions you may have about Arista.
Arista CloudVision complete solution
Never before has it been so easy to manage and monitor networks!
CloudVision is a comprehensive multifunctional NetOps management platform for managing networks. It offers features such as network visualization, configuration management, security monitoring and automated processes.
Companies should use Cloudvision to manage their infrastructure efficiently manage their infrastructure, optimize network performance, minimize security risks and and ensure compliance with guidelines. Through centralized management and monitoring can reduce costs, streamline operations and improve the overall security of their network. improve the overall security of their network.
- So simple is that.
Advantages of the CloudVision Platform:
- Centralized network management
- Automation and orchestration
- Network visualization
- Configuration management
- Scalability
- Real-time telemetry and monitoring
- Efficient network infrastructure management
- Optimization of network performance
- Minimization of security risks
- Ensuring compliance with guidelines
- Cost efficiency
- Rationalization of operational processes
- Improving the overall security of the network
Arista Ethernet switches
The Arista Ethernet switches provide the perfect networking solution for your demanding workloads. With native support for VMware virtualization and hundreds of Linux applications built into the hardware platforms that meet the most stringent power and cooling requirements of today's data centers, Arista offers the most efficient and best-performing solution for Ethernet platforms.
Arista 720 Series
The Arista 710P, 720X and 722XPM and 720D series switches deliver cloud grade performance and reliability with POE connectivity for all campus user workloads. Managed 802.3 power services deliver up to 60W, with speed options ranging from 10Mbps to 5Gbps over UTP.
| 10M-mGig Campus POE Switches |  |  |  |  |  |  |  |
|---|---|---|---|---|---|---|---|
| Model Name | 720DP-24S | 720DP-48S | 720DP-24ZS | 720DP-48ZS | 720DT-24S | 720DT-48S | 720DF-48Y |
| Ports | 24x RJ45 4x SFP+ | 48x RJ45 4x SFP+ | 24x RJ45 4x SFP+ | 48x RJ45 4x SFP+ | 24x RJ45 4x SFP+ | 48x RJ45 4x SFP+ | 48x SFP 4x SFP28 |
| 10M-1G PoE+ (30W 802.3af/at) | 24 | 48 | N.a. | N.a. | 24 | 48 | N.a. |
| 100M-2.5G PoE+ (60W 802.3bt) | N.a. | N.a. | 24 | 48 | N.a. | N.a. | 48 |
| 10G SFP+ Ports | 4 | 4 | 4 | 4 | 4 | 4 | N.a. |
| 25G SFP28 Ports | N.a. | N.a. | N.a. | N.a. | N.a. | N.a. | 4 |
| Throughput (FDX) | 64 (128 Gbps) | 88 (176 Gbps) | 100 (200 Gbps) | 160 (320 Gbps) | 64 (128 Gbps) | 88 (176 Gbps) | 148 (296 Gbps) |
| Packets/Second | 95 Mpps | 131 Mpps | 149 Mpps | 238 Mpps | 95 Mpps | 131 Mpps | 220 Mpps |
| Latency (RJ-45) | 1.2 µs | ||||||
| CPU | Dual-Core x86 | ||||||
| System Memory | 4 GB | 4 GB | 8 GB | 8 GB | 4 GB | 8 GB | 4 GB |
| System Flash | 8 GB | 8 GB | 8 GB | 8 GB | 8 GB | 16 GB | 8 GB |
| Packet Buffer | 2 MB | 4 MB | 8 MB | 8 MB | 2 MB | 4 MB | 2 MB |
| USB Ports | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Console Ports | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| 100M/1G Mgmt. port | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Airflow | Front to rear | Front to rear | Front to rear | Front to rear | Front to rear | Front to rear | Front to rear |
| Size (WxHxD) | 17.3 x 1.71 x 16.9 inches (44.0 x 4.4 x 43.0 cm) | 17.3 x 1.71 x 16.9 inches (44.0 x 4.4 x 43.0 cm) | 17.3 x 1.71 x 16.5 inches (44.0 x 4.4 x 42.0 cm) | 17.3 x 1.71 x 16.9 inches (44.0 x 4.4 x 43.0 cm) | 17.3 x 1.71 x 12.9 inches (44.0 x 4.4 x 32.7 cm) | 17.3 x 1.71 x 12.9 inches (44.0 x 4.4 x 32.7 cm) | 17.3 x 1.71 x 12.9 inches (44.0 x 4.4 x 32.7 cm) |
| Weight | 12.8 lbs (5.81 kg) | 14.83 lbs (6.73 kg) | 12.8 lbs (5.81 kg) | 17.63 lbs (8 kg) | 9.6 lbs (4.36 kg) | 10.22 lbs (4.64 kg) | TBD |
| Cooling Fans | 3 | 4 | 4 | 4 | 2 | 2 | 3 |
| Power Supply | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| EOS License Group | LIC-FIX-G | ||||||
| Minimum EOS | 4.28.2F | 4.29.1F | 4.29.2F | TBD | 4.28.2F | 4.29.1F | 4.29.0F |
| 710P / 722XPM Switches |  |  |  |  |
|---|---|---|---|---|
| Model Name | 710P-16P | 710P-12 | 722XPM-48ZY8 | 722XPM-48Y4 |
| Ports | 16x RJ45 2x 10G SFP | 12x RJ45 2x 10G SFP | 48x RJ45 8x 25G SFP | 48x RJ45 4x 25G, 4 10G SFP |
| 10M-1G UTP (30W)1 | 12 | 12 | N.a. | 48 |
| 100M-2.5G UTP (60W)2 | N.a. | N.a. | 48 | N/A |
| 1G-5G UTP (60W)2 | 2 | 0 | N.a. | N.a. |
| 1G-5G UTP3 | 2 | 0 | N.a. | N.a. |
| 10G | 2 | 2 | 0 | 4 |
| 25G | N.a. | N.a. | 8 | 4 |
| Throughput | 104Gbps (FDX) | 64Gbps (FDX) | 640Gbps (2 way) | 376Gbps (2 way) |
| Packets/Second | 155Mpps | 95Mpps | 952 Mpps | 559 Mpps |
| Latency (RJ45) | 1.2 µs | 1.2 µs | 1.2 µs | 1.2 µs |
| CPU | Dual Core-x86 | Dual Core-x86 | Dual Core-x86 | Dual Core-x86 |
| System Memory | 4GB | 4GB | 4GB | 4GB |
| System Flash | 8GB | 8GB | 8GB | 8GB |
| Packet Buffer | 2MB | 2MB | 8MB | 4MB |
| USB Port | 1 | 1 | 1 | 1 |
| Console Port | 1 | 1 | 1 | 1 |
| 100M/1G Management Port | N.a. | N.a. | 1 | 1 |
| Power (Max, excluding PoE) | 51W | 46W | 916W | 968W |
| Power Input | PoE pass through 150W external 280W external | 150W external 280W external | N.a. | N.a. |
| Airflow | N.a. | N.a. | Front-Rear (Port Side - Power) | Front-Rear/Rear-Front |
| 720XP Switches |  |  |  |  |  |  |
|---|---|---|---|---|---|---|
| Model Name | 720XP-48Y6 | 720XP-24Y6 | 720XP-96ZC2 | 720XP-48ZC2 | 720XP-24ZY4 | 720XP-48TXH-2C-S |
| Ports | 48x RJ45 6x 25G SFP | 24x RJ45 6x 25G SFP | 96x RJ45 4x 25G SFP 2y 100G QSFP | 48x RJ45 4x 25G SFP 2y 100G QSFP | 24x RJ45 4x 25G SFP | 48x RJ45 4x 25G SFP 2y 100G QSFP |
| 10M-1G UTP (30W 802.3af/t) | 48 | 24 | ||||
| 100M-2.5G UTP (30W 802.3af/t) | N.a. | N.a. | 0 | 40 | 16 | 0 |
| 100M-2.5G UTP (60W 802.3bt) | 0 | 0 | 80 | 0 | 0 | 0 |
| 100M-5G UTP (60W 802.3bt) | N.a. | N.a. | 16 | 8 | 8 | 0 |
| 100M-10G UTP (90W 802.3bt) | N.a. | N.a. | 0 | 0 | 0 | 48 |
| SFP-25G | 6 | 6 | 4 | 4 | 4 | 4 |
| QSFP-100G | N.a. | N.a. | 2 | 2 | N.a. | 2 |
| Throughput (FDX) | 198 (396)Gbps | 174 (348)Gbps | 580 (1160)Gbps | 440 (880)Gbps | 180 (360)Gbps | 780 (1560)Gbps |
| Packets/Second | 294Mpps | 259Mpps | 863Mpps | 654Mpps | 268Mpps | 1160Mpps |
| Latency (RJ-45) | 1.2 µs | 1.2 µs | 1.2 µs | 1.2 µs | 1.2 µs | 1.2 µs |
| CPU | Dual Core-x86 | Dual Core-x86 | Dual Core-x86 | Dual Core-x86 | Dual Core-x86 | Dual Core-x86 |
| System Memory | 4GB | 4GB | 4GB | 4GB | 4GB | 8GB |
| System Flash | 8GB | 8GB | 8GB | 8GB | 8GB | 16GB |
| Packet Buffer | 8MB | 16MB | 8MB | 8MB | 8MB | |
| USB Ports | 1 | 1 | 1 | 1 | 1 | 1 |
| Console Ports | 1 | 1 | 1 | 1 | 1 | 1 |
| 100M/1G Management Port | 1 | 1 | 1 | 1 | 1 | 1 |
| Airflow | Front-Rear Rear-Front | Front-Rear Rear-Front | Front-Rear | Front-Rear | Front-Rear | Front-Rear |
Arista 7020 & 7010 Series
The Arista 7020 and 7010 family of Ethernet switches combine a compact form factor, low power and cooling with performance, scalability, availability and operational ease to meet the demands of today’s higher performance enterprises.
| 1G / 10G Switches |  |  |  | |  | |
|---|---|---|---|---|---|---|
| Model Name | 7020SR-32C2 | 7020SR-24C2 | 7020TR-48 | 7020TRA-48 | 7010TX-48 | 7010TX-48-DC |
| Ports | 32x SFP+ 2x QSFP100 | 24x SFP+ 2x QSFP100 | 48x RJ45 6x SFP+ | 48x RJ45 6x SFP+ | 48x RJ45 4x SFP28 | 48x RJ45 4x SFP28 |
| Form Factor | 1 RU | 1 RU | 1 RU | 1 RU | 1 RU | 1 RU |
| Switching Throughput | 1.04 Tbps | 880 Gbps | 216 Gbps | 216 Gbps | 296 Gbps | 296 Gbps |
| Max Forwarding Rate | 300 Mpps | 300 Mpps | 162 Mpps | 162 Mpps | 220 Mpps | 220 Mpps |
| Latency | Under 3.8 µs | Under 3.8 µs | Under 3.8 µs | Under 3.8 µs | Under 2.8 µs | Under 2.8 µs |
| System Buffer | 3GB | 3GB | 3GB | 3GB | 4MB Shared | 4MB Shared |
| MAC Table Size | Up to 256K | Up to 256K | Up to 256K | Up to 256K | Up to 64K | Up to 64K |
| Maximum IPv4 Hosts | Up to 64K | Up to 64K | Up to 64K | Up to 64K | Up to 32K | Up to 32K |
| Maximum IPv6 Hosts | Up to 64K | Up to 64K | Up to 64K | Up to 64K | Up to 16K | Up to 16K |
| IPv4/IPv6 Routes | 32K/16K | 32K/16K | 32K/16K | 32K/16K | 16K | 16K |
| IPv4/IPv6 FlexRoute | 200K/100K | 200K/100K | 200K/100K | 200K/100K | N.a. | N.a. |
| ECMP Fanout | 128-Way | 128-Way | 128-Way | 128-Way | N.a. | N.a. |
| LAG Members | 32 Ports / Channel | 32 Ports / Channel | 32 Ports / Channel | 32 Ports / Channel | N.a. | N.a. |
| LAG Groups | 32 groups per system | 32 groups per system | 54 groups per system | 54 groups per system | N.a. | N.a. |
| ACL Entries | 12K | 12K | 12K | 12K | N.a. | N.a. |
| Power Supplies | 2 (1+1 Redundant) | 2 (1+1 Redundant) | 2 (1+1 Redundant) | 2 (1+1 Redundant) | 2 (1+1 Redundant) | 2 (1+1 Redundant) |
| AC and DC | ✔ | ✔ | ✔ | ✔ | Dual AC power supplies 100-240V AC | Dual DC power supplies -40V to 72V DC |
| Fans | 2 hot swappable | 3 hot swappable | 4 hot swappable | 4 hot swappable | 2 hot swappable (1+1 Redundant) | 2 hot swappable (1+1 Redundant) |
| Airflow | F/R or R/F | F/R or R/F | F/R or R/F | F/R or R/F | F/R or R/F | F/R or R/F |
| CloudVision® | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| Smart System Upgrade* | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| ZTP | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| VM Tracers | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| AEM | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| VXLAN | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| LANZ | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| Hitless Speed Changes | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| Typical Power | 160W | 95W | 105W | 115W | 91W | 96W |
Arista 7050X3 Series
The Arista 7050X3 Series are purpose built data center switches in compact and energy efficient form factors with wire speed layer 2 and layer 3 features combined with low latency and advanced EOS features for software defined cloud networking. The 7050X3 supports a flexible combination of speeds including 1/10G, 25G, 40G and 100G that allows customers to design networks to accommodate the myriad different applications and east-west traffic patterns found in modern data centers.
| Flexible 10/25/40/50/100G |  |  |  |  |  |  |  |
|---|---|---|---|---|---|---|---|
| Model Name | 7050CX3-32S | 7050CX3M-32S | 7050SX3-96YC8 | 7050SX3-48YC12 | 7050SX3-48YC8 | 7050SX3-48C8 | 7050TX3-48C8 |
| Ports | 32x 100G QSFP 2x 10G SFP | 32x 100G QSFP 2x 10G SFP | 96x 25G SFP 8x 100G QSFP | 48x 25G SFP 12x 100G QSFP | 48x 25G SFP 8x 100G QSFP | 48x 10G SFP 8x 100G QSFP | 48x 10G RJ45 8x 100G QSFP |
| Switch Height | 1RU | 1RU | 2RU | 1RU | 1RU | 1RU | 1RU |
| Maximum 100GbE Ports | 32 | 32 | 8 | 12 | 8 | 8 | 8 |
| Maximum 50GbE Ports | 64 | 64 | 16 | 24 | 16 | 16 | 16 |
| Maximum 40GbE Ports | 32 | 32 | 8 | 12 | 8 | 8 | 8 |
| Maximum 25GbE Ports | 128 | 128 | 128 | 96 | 64 | 16 | 16 |
| Maximum 10GbE Ports | 129 | 129 | 129 | 96 | 64 | 64 | 64 |
| Maximum 1GbE Ports | 2 | 2 | 129 | 48 | 48 | 48 | 48 |
| L2/L3 Throughput | 6.4 Tbps | 6.4 Tbps | 6.4 Tbps | 4.8 Tbps | 4.0 Tbps | 2.56 Tbps | 2.56 Tbps |
| L2/L3 PPS | 2 Bpps | 2 Bpps | 2 Bpps | 2 Bpps | 1 Bpps | 1 Bpps | 1 Bpps |
| Latency | 800ns | 800ns | 800ns | 800ns | 800ns | 800ns | 3usec |
| Typical Power Draw | 192W | 398W | 218W | 179W | 124W | 124W | 212W |
| AC and DC | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Total System Buffer | 32MB | 32MB | 32MB | 32MB | 32MB | 32MB | 32MB |
| CloudVision | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Smart System Upgrade * | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| ZTP | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| VM Tracer | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| AEM | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| VXLAN Routing | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| LANZ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| DLB * | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| NAT | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Hitless Speed Changes | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Airflow | F/R or R/F | F/R or R/F | F/R or R/F | F/R only | F/R or R/F | F/R or R/F | F/R or R/F |
Arista 7050X4 Series
The Arista 7050X4 Series are a range of purpose built data center high performance switches in compact and energy efficient form factors with wire speed layer 2 and layer 3 features combined with low latency and advanced EOS features for software defined cloud networking. These series supports a flexible combination of speeds from 10G to 400G that allows customers to design networks to accommodate the myriad different applications and east-west traffic patterns found in modern data centers.
| Flexible 100G/400G |  |  | |  | |  |  |
|---|---|---|---|---|---|---|---|
| Model Name | 7050PX4-32S | 7050DX4-32S | 7050DX4M-32S | 7050SDX4-48D8 | 7050SPX4-48D8 | 7050CX4-24D8 | 7050CX4M-48D8 |
| Ports | 32x 400G OSFP 2x SFP+ | 32x 400G QSFP-DD 2x SFP+ | 32x 400G QSFP-DD 2x SFP+ | 48x 100 SFP-DD 8x 400 QSFP-DD | 48x 100 DSFP 8x 400 QSFP-DD | 24x 200 QSFP56 8x 400 QSFP-DD | 48x 100 QSFP28 8x 400 QSFP-DD |
| Maximum 400G Ports | 32 | 32 | 32 | 8 | 8 | 8 | 8 |
| Maximum 200G Ports | 64 | 64 | 64 | 16 | 16 | 16 | 16 |
| Maximum 100G Ports | 128 | 128 | 128 | 72 | 72 | 72 | 72 |
| Maximum 50G Ports | 128 | 128 | 128 | 72 | 72 | 72 | 72 |
| Maximum 40G Ports | 64 | 64 | 64 | 8 | 8 | 8 | 8 |
| Maximum 25G Ports | 128 | 128 | 128 | 72 | 72 | 72 | 72 |
| Maximum 10G Ports | 128+2 | 128+2 | 128+2 | 72 | 72 | 72 | 72 |
| L2/L3 Throughput | 12.8 Tbps | 12.8 Tbps | 12.8 Tbps | 8.0 Tbps | 8.0 Tbps | 8.0 Tbps | 8.0 Tbps |
| L2/L3 PPS | Up to 5.3 Bpps | Up to 5.3 Bpps | Up to 5.3 Bpps | 2.7 Bpps | 2.7 Bpps | 2.7 Bpps | 2.7 Bpps |
| Latency | 900 µs | 900 µs | 900 µs | 900 µs | 900 µs | 900 µs | 900 µs |
| Typical Power Draw | 353W | 353W | TBD | TBD | TBD | TBD | TBD |
| AC and DC | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Total System Buffer | 132MB | 132MB | 132MB | 82MB | 82MB | 82MB | 82MB |
| RU | 1 | 1 | 1 | 1 | 1 | 1 | 2 |
| MACSec Encryption | N.a. | N.a. | 16 Ports | N.a. | N.a. | N.a. | 56 |
| CloudVision | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Smart System Upgrade | ✔* | ✔* | ✔* | ✔* | ✔* | ✔* | ✔* |
| ZTP | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| VM Tracer | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| AEM | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| LANZ | ✔* | ✔* | ✔* | ✔* | ✔* | ✔* | ✔* |
| Hitless Speed Changes | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Airflow | Front to Rear or Rear to Front | Front to Rear or Rear to Front | Front to Rear | Front to Rear or Rear to Front | Front to Rear or Rear to Front | Front to Rear or Rear to Front | Front to Rear or Rear to Front |
Arista 7060 Series
The Arista 7060X and 7260X Series are a range of 1RU and 2RU high performance 25G, 40G, 100G, 400G and 800G high density, fixed configuration, data center switches with wire speed layer 2 and layer 3 features, and advanced features for software driven cloud networking. Both series deliver a rich choice of interface speed and density allowing networks to seamlessly evolve from 10G/40G to 25G/100G and 400G/800G.
| Cloud Optimized 10G - 800G |  |  |  |  |  |  |
|---|---|---|---|---|---|---|
| Modell Name | 7060DX5-64E | 7060PX5-64E | 7060DX5-64S | 7060DX5-32 | 7060X6-64PE | 7060X6-32PE |
| Description | 32x 800G QSFP-DD800 | 32x 800G OSFP800 | 64x 400G QSFP-DD | 32x 400G QSFP-DD | 64x 800G OSFP800 | 32x 800G OSFP800 |
| Maximum 800G | 32 | 32 | - | - | 64 | 32 |
| Maximum 400G | 64 | 64 | 64 | 32 | 128 | 64 |
| Maximum 200G | 128 | 128 | 128 | 64 | 256 | 128 |
| Maximum 100G | 256 | 256 | 256 | 128 | 320 | 256 |
| Maximum 50G | 256 | 256 | 256 | 128 | 320 | 256 |
| Maximum 40G | 32 | 32 | 64 | 32 | N.a. | N.a. |
| Maximum 25G | 128 | 128 | 256 | 128 | N.a. | N.a. |
| Maximum 10G | 128 | 128 | 256 | 128 + 1 | N.a. | N.a. |
| L2/L3 Throughput | 25.6 Tbps | 25.6 Tbps | 25.6 Tbps | 12.8 Tbps | N.a. | N.a. |
| L2/L3 PPS | 10.6 Bpps | 10.6 Bpps | 10.6 Bpps | 5.3 Bpps | N.a. | N.a. |
| Latency | From 850 µs | From 850 µs | From 850 µs | From 850 µs | From 700 µs | From 700 µs |
| Typical System Power Draw | TBD | TBD | TBD | TBD | N.a. | N.a. |
| Total System Buffer | 114 MB | 114 MB | 114 MB | 57 MB | 165 MB | 84 MB |
| RU | 1 | 1 | 2 | 1 | 2 | 1 |
| CloudVision | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Smart System Upgrade* | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| ZTP | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| VM Tracer | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| AEM | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| VXLAN | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| LANZ* | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| Hitless Speed Changes | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Airflow | Front to Rear | Front to Rear | Front to Rear | F/R or R/F | Front-Rear | Front-Rear |
| AC and DC PSU | ✔ | ✔ | N.a. | ✔ | ✔ | ✔ |
| Cloud Optimized 10G - 400G |  | |  |  |  |  |
|---|---|---|---|---|---|---|
| Modell Name | 7060CX2-32S | 7060SX2-48YC6 | 7060CX-32S | 7260CX-64 | 7060PX4-32 | 7060DX4-32 |
| Description | 32x 100G QSFP 2x SFP+ | 48x 10/25G SFP 6x QSFP100 | 32x 100G QSFP 2x SFP+ | 64x 100G QSFP 2x SFP+ | 32x 400G OSFP 2x SFP+ | 32x 400G QSFP-DD 2x SFP+ |
| Maximum 400G Ports | - | - | - | - | 32 | 32 |
| Maximum 200G Ports | - | - | - | - | 64 | 64 |
| Maximum 100G Ports | 32 | 6 | 32 | 64 | 128 | 128 |
| Maximum 50G Ports | 64 | 12 | 64 | 128 | 128 | 128 |
| Maximum 40G Ports | 32 | 6 | 32 | 64 | 64 | 64 |
| Maximum 25G Ports | 128 | 72 | 128 | 256 | 128 | 128 |
| Maximum 10G Ports | 130 | 72 | 130 | 258 | 130** | 130** |
| SFP Ports | 2 | 48 | 2 | 2 | 2 | 2 |
| L2/L3 Throughput | 6.4 Tbps | 3.6 Tbps | 6.4 Tbps | 12.8 Tbps | 12.8 Tbps | 12.8 Tbps |
| L2/L3 PPS | 3.3 Bpps | 2.7 Bpps | 3.3 Bpps | 9.52 Bpps | 8 Bpps | 8 Bpps |
| Latency | 450ns | 450ns | 450ns | 550 to 1500ns | 700ns | 700ns |
| Typical Power Draw | 187W | 240W | 187W | 1672W | 342W | 342W |
| AC and DC | ✔ | ✔ | ✔ | Future | ✔ | ✔ |
| Total System Buffer | 22MB | 22MB | 16MB | 64MB | 64MB | 64MB |
| RU | 1 | 1 | 1 | 2 | 1 | 1 |
| CloudVision | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Smart System Upgrade | ✔ | ✔ | ✔ | ✔ | ✔* | ✔* |
| ZTP | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| VM Tracer | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| AEM | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| VXLAN | ✔ | ✔ | ✔ | ✔ | N.a. | N.a. |
| LANZ | ✔ | ✔ | ✔ | ✔ | ✔* | ✔* |
| Hitless Speed Changes | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ |
| Airflow | F/R or R/F | F/R or R/F | F/R or R/F | F/R or R/F | Front to Rear | Front to Rear |
Arista 7130 Series
The Arista 7130 Series are a family of ultra low latency layer 1 crosspoint platforms, with optional FPGAs, that enable network applications, multiplexing, filtering and timestamping with unparalleled latency from only 5 ns.
| Ultra Low Latency - Layer 1+ Switches |  |  |  | |
|---|---|---|---|---|
| Model Name | 7130LBR-4856QD | 7130B-32 | 7132LB-48Y4C | 7135LB-48Y4C |
| Front-Panel Ports | 48x SFP+, 6x QSFP-DD (10G NRZ) | 32x QSFP-DD (8 x 10G NRZ or 10/25G NRZ) | 48x SFP28, 4x QSFP28 | 48x SFP28, 4x QSFP28 |
| Layer 1 Crosspoint Interfaces | N.a. | N.a. | 256 | N.a. |
| Layer 1 Throughput | 100M-11.3Gbps per lane | 100M-11.3Gbps per lane/td> | N.a. | 100M-25.8Gbps per lane |
| Layer 1 Latency | From 6 ns | From 7 ns | N.a. | From 7 ns |
| FPGA | 2x Xilinx UltraScale+ VU9P-3 | N.a. | 1x Xilinx UltraScale+ VU9P-3 | 1x Xilinx UltraScale+ VU9P-3 |
| FPGA DRAM | 32GB DDR4 per FPGA | N.a. | 4x 8GB DDR4 | 4x 8GB DDR4 |
| FPGA Crosspoint Interface | 48x 10GbE per FPGA | N.a. | N.a. | N.a. |
| R-Series Switch Throughput | 1.5 Tbps | 2.56 (5.12) Tbps | N.a. | N.a. |
| R-Series Switch Packet Buffer | 4 GB | 22 MB | N.a. | N.a. |
| Internal Switch Interfaces | 48 x 10GbE lanes to each FPGA, 48x 10GbE lanes to crosspoint, 4x 10GbE to CPU | 256x 10G | N.a. | N.a. |
| Vitis™ Development Kit (VDK) | ✔1 | N.a. | ✔1 | ✔1 |
| Clock | OCXO | OCXO | OCXO | OCXO |
| CPU | 8-core x86 | 8-core x86 | 8-core x86 | 8-core x86 |
| System DRAM/SSD | 64GB / 120GB | 32GB / 120GB | 32GB DDR4 / 120GB | 32GB / 120GB |
| RS-232 Serial Ports | 1 (RJ-45) | 1 (RJ-45) | 1 (RJ-45) | 1 (RJ-45) |
| USB Ports | 1 | 1 | 1 | 1 |
| 100/1000 Management Ports | 1 | 1 | 1 | 1 |
| PPS Input Ports (SV TTL, 500 or Hi-Z) | 2 | 2x SMA | 1 | 1 |
| PPS Output Ports (5V TTL) | 2 | 2x SMA | 1 | 1 |
| Hot-swap Power Supplies | 2(1+1 redundant) | 2(1+1 redundant) | 2(1+1 redundant) | 2(1+1 redundant) |
| Hot-swappable Fans | 3 (N+1 redundant) | 4 (N+1 redundant) | 2 (N+1 redundant) | 3 (N+1 redundant) |
| Reversible Airflow Option | ✔ | ✔ | ✔ | ✔ |
| Typical/Max Power Draw | TBD | 1600W/2400W | 367W/550W | 667W/1000W |
| Rack Units | 1U | 2U | 1U | 1U |
| Size (WxHxD) | 17.32 x 44.0 x 25.75 inches (44.0 x 112 x 65.4 cm) | 17.32 x 8.8 x 30.00 inches (44.0 x 22.3 x 76.2 cm) | 17.3 x 4.4 x 18.61 inches (44.0 x 11.2 x 47.2 cm) | 17.3 x 4.4 x 22.4 inches (44.0 x 11.2 x 56.9 cm) |
| Weight | 32.9 lbs (14.9 kg) | 50.5 lbs (22.9 kg) | 21.6 lbs (9.8 kg) | 26.8 lbs (12.2 kg) |
| Fan Tray | FAN-7011H | 7012H | FAN-7011M | FAN-7011H |
| Power Supplies | PWR-1511-AC or PWR-1511-DC | PWR-2411-AC or PWR-2411-DC | PWR-1011-AC or PWR-1011-DC | PWR-1511-AC or PWR-1511-DC or PWR-1512-AC |
| EOS Feature Licenses | Group 4 | N.a. | Group 2 | Group 3 |
| Minimum EOS | 4.28.0F | 4.28.01 | 4.30.2 | TBD |
| Ultra Low Latency - Layer 1+ Switches |  | | | | ||||
|---|---|---|---|---|---|---|---|---|
| Model Name | 7130-96LBS | 7130-48LBS | 7130-48G3S | 7130-48EHS | ||||
| Front-Panel Ports | 96x SFP+ | 48x SFP+ | 48x SFP+ | 48x SFP+ | ||||
| Port-to-port Latency | From 5ns | From 5ns | From 5ns | From 5ns | ||||
| RU | 2 | 1 | 1 | 1 | ||||
| 1.92 Tbps | 960 Gbps | 960 Gbps | 960 Gbps | |||||
| Datasheet | 7130-48EHS | 7130-96LBS | 7130-48LBS | 7130-48G3S |
Arista 7170 Series
The Arista 7170 series are highly programmable and scalable 100G data center switches with comprehensive layer 2 and layer 3 features. They combine a high performance forwarding engine with a programmable data plane with custom forwarding profiles to add new functionality for a diverse set of use-cases. Offering a choice of systems with up to 64 ports of 100G the 7170 can be deployed in both leaf and spine roles.
| Multi-function Programmable Leaf and Spine Switches |  |  |  |  |
|---|---|---|---|---|
| Model Name | 7170B-64C | 7170-64C | 7170-32C | 7170-32CD |
| Ports | 64x 100G QSFP 2x 10G SFP+ | 64x 100G QSFP 2x 10G SFP+ | 32x 100G QSFP 2x 10G SFP+ | 32x 100G QSFP 2x 10G SFP+ |
| Maximum 100G Ports | 64 | 64 | 32 | 32 |
| Maximum 50G Ports | 128 | 128 | 64 | 64 |
| Maximum 40G Ports | 64 | 64 | 32 | 32 |
| Maximum 25G Ports | 128 | 256 | 128 | 128 |
| Maximum 10G Ports | 130 | 258 | 130 | 130 |
| Switch Height | 2RU | 2RU | 1RU | 1RU |
| L2/L3 Throughput (FDX) | 6.4 (12.8) Tbps | 6.4 (12.8) Tbps | 3.2 (6.4) Tbps | 3.2 (6.4) Tbps |
| Max Forwarding Rate (pps) | 3.2 Bpps | 4.8 Bpps | 2.4 Bpps | 2.4 Bpps |
| Latency* | From 1 us | From 800 ns | From 800 ns | From 800 ns |
| Packet Buffer | 64MB Fully Shared | 22MB Fully Shared | 20MB Fully Shared | 20MB Fully Shared |
| CPU | Multi Core x86 | Dual Core x86 | Dual Core x86 | Dual Core x86 |
| Memory (Optional) | 64GB | 16GB (64GB) | 16GB (32GB) | 16GB |
| SSD (Optional) | 120GB | 30GB (+120GB) | 30GB (+30GB) | 30GB |
| Pipeline Stages | 80 | 24 | 48 | 24 |
| MACsec | ✔ | No | No | No |
| Typical Power Draw | 12.5W per port | 5W per port | 7W per port | 7W per port |
| Airflow | Front to Rear | Front to Rear or Rear to Front | ||
Arista 7280 Series
The Arista 7280R3 Series provides a combination of dynamic and deep buffers, high performance and full internet scale routing in high density and flexible fixed and modular configuration switch routers combined with extensive features such as INT, VXLAN and Accelerated sFlow. The 7280R3 are built for next generation Cloud and IP storage, content delivery networks, and internet peering in lossless two-tier designs, equally suited to the Universal spine or data center edge.
| Dynamic Deep Buffer 25/50/100/400G |  |  |  |  |  |
|---|---|---|---|---|---|
| Model Name | 7280R3A Modular 7280R3AM Modular 7280R3AK Modular | 7280DR3A-54 7280DR3AM-54 7280DR3AK-54 | 7280DR3A-36 7280DR3AM-36 7280DR3AK-36 | 7280PR3-24 7280PR3K-24 7280DR3-24 7280DR3K-24 | 7280CR3A-24D12 7280CR3AM-24D12 7280CR3AK-24D12 |
| Ports | 36x 400G OSFP or QSFP-DD 144x 100G QSFP | 54x 400G QSFP-DD | 36x 400G QSFP-DD | 24x 400G OSFP or QSFP-DD | 24x 100G QSFP 12x 400G QSFP-DD |
| Port-to-port Latency | From 4usec | From 4usec | From 4usec | From < 4usec | From 4usec |
| RU | 4 | 2 | 2 | 1 | 1 |
| Switching Capacity | 14.4 Tbps | 21.6 Tbps | 14.4 Tbps | 9.6 Tbps | 7.2 Tbps |
| Datasheet | 7280R3A M. | 7280R3A | 7280R3A | 7280R3A | 7280R3A |
| Dynamic Deep Buffer 25/50/100/400G |  |  |  |  | |
|---|---|---|---|---|---|
| Model Name | 77280CR3MK-32P4 7280CR3MK-32D4 | 7280CR3A-48D6 7280CR3AM-48D6 7280CR3AK-48D6 | 7280CR3A-32S 7280CR3AM-32S 7280CR3AK-32S | 7280CR3-36S 7280CR3K-36S | 7280CR3-32P4 7280CR3K-32P4 7280CR3-32D4 7280CR3K-32D4 |
| Ports | 32x 100G QSFP 4x 400G OSFP or QSFP-DD | 48x 100G QSFP 6x 400G QSFP-DD | 32x 100G QSFP with up to 2x 400G QSDP-DD Ports | 36x 100G QSFP with up to 2x 400G QSFP-DD ports | 32x 100G QSFP 4x 400G OSFP or QSFP-DD |
| Port-to-port Latency | From < 4usec | From 4usec | From 4usec | From 4usec | From < 4usec |
| RU | 1 | 2 | 1 | 1 | 1 |
| Switching Capacity | 4.8 Tbps | 7.2 Tbps | 3.6 Tbps | 2.4 Tbps | 4.8 Tbps |
| Datasheet | 7280CR3MK | 7280CR3AK | 7280CR3AK | 7280CR3 | 7280CR3 |
| Dynamic Deep Buffer 25/50/100/400G |  | |  |  |  |  |
|---|---|---|---|---|---|---|
| Model Name | 7280SR3A-48YC8 7280SR3AM-48YC8 7280SR3AK-48YC8 | 7280SR3-48YC8 7280SR3K-48YC8 | 7280SR3-40YC6 | 7280CR3A-72 7280CR3AM-72 7280CR3AK-72 | 7280CR3-96 7280CR3K-96 | 7280PR3-48 7280DR3-48 |
| Ports | 48x 50G SFP 6x 200G / 8x 100G QSFP | 48x 25G SFP 8x 100G QSFP | 40x 25G SFP 6x 100G QSFP | 72x 100G QSFP | 96x 100G QSFP | 48 x 400G OSFP or QSFP-DD |
| Port-to-port Latency | From 4usec | From 4usec | From 4usec | From 4usec | From < 4usec | From 4usec |
| RU | 1 | 1 | 1 | 2 | 2 | 2 |
| Switching Capacity | 3.6 Tbps | 2.4 Tbps | 800 Gbps | 7.2 Tbps | 9.6 Tbps | 19.2 Tbps |
| Datasheet | 7280SR3A | 7280SR3 | 7280SR3 | 7280CR3A | 7280CR3 | 7280PR3 |
Arista 7260X & 7060 Series
Arista's 7060X and 7260X series are the industry's first high-density 100GbE fixed-configuration switches, supporting both 10GbE and 25GbE in compact 1RU and 2RU designs. They combine scalable L2 and L3 forwarding and traffic management with advanced features for non-stop operation, network visibility, and network virtualization to deliver the network performance required for cloud data centers, enterprise networks, and HPC environments.
| 7260X / 7060 Series | | | |  | |  |
|---|---|---|---|---|---|---|
| Model Name | 7060CX2-32S | 7060SX2-48YC6 | 7060CX-32S | 7260QX-64 | 7260CX-64 | 7260CX3-64 |
| Ports | 32x 100G QSFP 2x SFP+ | 48x 10/25G SFP 6x QSFP100 | 32x 100G QSFP 2x SFP+ | 64x QSFP+ 2x SFP+ | 64x 100G QSFP 2x SFP+ | 64x 100G QSFP 2x SFP+ |
| Maximum 100G Ports | 32 | 6 | 32 | - | 64 | 64 |
| Maximum 40G Ports | 32 | 6 | 32 | 64 | 64 | 64 |
| Maximum 10G Ports | 130 | 72 | 130 | 2 | 258 | 130 |
| Maximum 25G Ports | 128 | 72 | 128 | - | 256 | 128 |
| Maximum 50G Ports | 64 | 12 | 64 | - | 128 | 128 |
| SFP Ports | 2 | 48 | 2 | 2 | 2 | 2 |
| L2/L3 Throughput | 6.4 Tbps | 3.6 Tbps | 6.4 Tbps | 5.12 Tbps | 12.8 Tbps | 12.8 Tbps |
| L2/3 PPS | 3.3 Bpps | 2.7 Bpps | 3.3 Bpps | 3.3 Bpps | 9.52 Bpps | 4.2 Bpps |
| Latency | 450ns | 450ns | 450ns | 550ns | 550 to 1500ns | 450ns |
| Typische Leistungsentnahme | 220W | 240W | 220W | 315W | 1672W | 340W |
| AC und DC | Ja | Ja | Ja | Future | Future | Ja |
| System Buffer | 22MB | 22MB | 16MB | 16MB | 64MB | 42MB |
| RU | 1 | 1 | 1 | 2 | 2 | 2 |
| CloudVision | Ja | Ja | Ja | Ja | Ja | Ja |
| Smart System Upgrade | Ja | Ja | Ja | Ja | Ja | Ja |
| ZTP | Ja | Ja | Ja | Ja | Ja | Ja |
| VM Tracer | Ja | Ja | Ja | Ja | Ja | Ja |
| AEM | Ja | Ja | Ja | Ja | Ja | Ja |
| VXLAN | Ja | Ja | Ja | Ja | Ja | Ja |
| LANZ | Ja | Ja | Ja | Ja | Ja | Ja |
| Hitless Speed Changes | Ja | Ja | Ja | NA | Ja | Ja |
| Airflow | F/R or R/F | F/R or R/F | F/R or R/F | F/R or R/F | F/R or R/F | F/R or R/F |
Arista 7500 Series
Arista's 7500E series modular systems are high-performance data center switches available in compact 7RU (4-slot) or 11RU (8-slot) configurations. They combine scalable L2 and L3 forwarding and traffic management with advanced features for network monitoring, precise timing, and network virtualization to deliver deterministic network performance for mission-critical data centers, cloud computing, enterprise, and HPC environments.
| 7500 Series |  |  |  |  |  |  |
|---|---|---|---|---|---|---|
| Model Name | 7516R | 7512R | 7508R | 7504R | 7508E | 7504E |
| Switching Capacity | 150Tbps | 115Tbps | 75Tbps | 38Tbps | 30Tbps | 15Tbps |
| Linecard Capacity | 9.6 Tbps | 9.6 Tbps | 9.6 Tbps | 9.6 Tbps | 3.84 Tbps | 3.84 Tbps |
| 10GbE Ports | 2,304 | 1,728 | 1,152 | 576 | 1152 | 576 |
| 25GbE Ports | 2,304 | 1,728 | 1,152 | 576 | - | - |
| 40GbE Ports | 576 | 432 | 288 | 144 | 288 | 144 |
| 50GbE Ports | 1,152 | 864 | 576 | 288 | - | - |
| 100GbE Ports | 576 | 432 | 288 | 144 | 96 | 48 |
| Forwarding Rate | 69 Bpps | 51 Bpps | 34.5 Bpps | 17.3 Bpps | 14.4 Bpps | 7.2 Bpps |
| System Buffer | 384GB | 288GB | 192GB | 96GB | 144GB | 72GB |
| Rack Units | 29 | 18 | 13 | 7 | 11 | 7 |
Other Arista series and Switch models
We offer the full Arista range, including big tower switches from 7-32 U with up to 1000+ ports. This includes the following models: 7050QX-32S, 7358X4, 7388X5, 7368X4, 7512R3, 7508R3, 7504R3, 7816LR3, 7816R3, 7812R3, 7808R3, 7804R3
If you require further information on the individual switches, please contact us.
Arista Cables and Transceivers
Arista's optical modules and cables offer customers a variety of high-density, low-power connectivity options for 100Mb, 1Gb, 10Gb, 20Gb, 40Gb, 100Gb, 200Gb, 400Gb, 800Gb Ethernet over fiber or copper.
| Transceiver & Connector | ||
|---|---|---|
| 10/100/1000 RJ45 | Type | Media/Reach |
| 7050T, 7050TX, 7010T | Cat5e, Cat6, Cat6A, Cat7 | 100m |
| 1GbE SFP | Type | Media/Reach |
| All SFP/SFP+ Ports | 1000BASE-SX | 50µ MMF / 550m |
| 1000BASE-LX | 9µ SMF / 10km | |
| 1000BASE-T | Cat5e / 100m | |
| 10GBASE-T RJ45 | Type | Media/Reach |
| All 10GBASE-T Ports | Cat5e/6 U/UTP | 55m |
| Cat6/6A F/UTP | 100m | |
| Cat7 S/FTP | 100m | |
| 10G Optical SFP+ | Type | Media/Reach |
| All SFP/SFP+ Ports | 10GBASE-SRL | 50µ MMF / 100m |
| 10GBASE-SR | 50µ MMF / 300m | |
| 10GBASE-LRL | 9µ SMF / 1km | |
| 10GBASE-LR | 9µ SMF / 10km | |
| 10GBASE-ERLBD | 9µ SMF, Single FIber / 30km | |
| 10GBASE-ER | 9µ SMF / 40km | |
| 10GBASE-ERBD | 9µ SMF, Single FIber / 40km | |
| 10GBASE-ZR | 9µ SMF / 80km | |
| 10GBASE-DWDM (Tunable) | 9µ SMF / 80km | |
| 10GBASE-AOC | Pre-terminated in 3, 5, 7, 10, 15, 20, 25, 30m lengths | |
| 10G Copper SFP+ | Type | Media/Reach |
| All SFP+ Ports | 10GBASE-CR Twinax / 'Direct Attach' | Pre-terminated in 0.5m, 1m, 1.5m, 2m, 2.5m 3m, 5m lengths |
| All SFP25 ports, and select SFP+ ports. Refer to Transceiver and Cable Guide for supported platforms. | 10GBASE-T | 30m over Cat6a 100m over Cat5e @ 1G/100M |
| Select SFP25 and SFP+ ports. Refer to Transceiver and Cable Guide for supported platforms. | 10GBASE-MRA-T | 30m over Cat6a @10G 100m over Cat5e @ 1G/100M |
| 25G Optics SFP | 10GBASE-MRA-T | 30m over Cat6a @10G 100m over Cat5e @ 1G/100M |
| All 25G SFP Ports | 25GBASE-SR & 25GBASE-MR-SR | 50µ MMF / 70m (OM3), 100m (OM4) |
| 25GBASE-MR-XSR | 50µ MMF / 200m (OM3), 300m (OM4) | |
| 25GBASE-LR & 25GBASE-MR-LR | 9µ SMF / 10km | |
| 25GBASE-AOC | Pre-terminated in 3, 5, 7, 10, 15, 20, 25, 30m lengths | |
| 25G Copper SFP | Type | Media/Reach |
| All 25G SFP Ports | 25GBASE-CR Twinax / 'Direct Attach' | Pre-terminated in 1m, 2m, 3m, 5m lengths |
| 50G Copper SFP | Type | Media/Reach |
| All 50GSFP, SFP-DD, and DSFP ports | 50GBASE-CR Twinax / 'Direct Attach' | Pre-terminated in 1m, 2m and 3m lengths |
| 100G Copper SFP-DD | Type | Media/Reach |
| All SFP-DD ports | 100GBASE-CR2 Twinax / 'Direct Attach' | Pre-terminated in 1m, 2m and 3m lengths |
| 100GBASE-CR2 to 2x 50GBASE-CR Twinax | Pre-terminated in 1m, 2m and 3m lengths | |
| 100G Copper DSFP | Type | Media/Reach |
| All DSFP ports | 100GBASE-CR2 Twinax / 'Direct Attach' | Pre-terminated in 1m, 2m and 3m lengths |
| 100GBASE-CR2 to 2x 50GBASE-CR | Pre-terminated in 1m, 2m and 3m lengths | |
| 40G Optical QSFP | Type | Media/Reach |
| All QSFP+ Ports | 40GBASE-SR4 | 50µ MMF / 100m (OM3), 150m (OM4) |
| 40GBASE-XSR4 | 50µ MMF / 300m (OM3), 400m (OM4) | |
| 40GBASE-BIDI | 50µ MMF / 100m | |
| 40GBASE-UNIV | 50µ MMF / 150m, 9µ SMF / 500m | |
| 40GBASE-LR4 | 9µ SMF / 10km | |
| 40GBASE-LRL4 | 9µ SMF / 1km | |
| 40GBASE-PLR4 | 9µ SMF / 10km | |
| 40GBASE-PLRL4 | 9µ SMF/1km | |
| 40GBASE-ER4 | 9µ SMF/40km | |
| 40GBASE-AOC | Pre-Terminated 3, 5, 7, 10, 15, 20, 25, 30,50, 75, 100m lengths | |
| 40G Copper QSFP | Type | Media/Reach |
| All QSFP+ Ports | 40GBASE-CR4 Twinax / 'Direct Attach' 40G to 40G | Pre-terminated in 0.5m, 1m, 2m, 3m, 5m lengths |
| 40GBASE-CR4 to 4 x 10G-CX1 40G to 10G | Pre-terminated in 0.5m, 1m, 2m, 3m, 5m lengths | |
| 100G Optical QSFP | Type | Media/Reach |
| All QSFP100 Ports | 100GBASE-AOC | Pre-Terminated 1, 3, 5, 7, 10, 15, 20, 25, 30m lengths |
| 100GBASE-SR4 | 50µ MMF / 70m (OM3), 100m (OM4) | |
| 100GBASE-XSR4 | 50µ MMF / 150m (OM3), 300m (OM4) | |
| 100GBASE-SWDM4 | 50µ MMF / 70m (OM3), 100m (OM4) | |
| 100GBASE-BIDI | 50µ MMF / 70m (OM3), 100m (OM4) | |
| 100GBASE-PSM4 | 9µ SMF / 500m | |
| 100GBASE-PLRL4 | 9µ SMF / 2km | |
| 100GBASE-CWDM4 | 9µ SMF / 2km | |
| 100GBASE-XCWDM4 | 9µ SMF / 10km | |
| 100GBASE-DR | 9µ SMF / 500m | |
| 100GBASE-FR | 9µ SMF / 2km | |
| 100GBASE-LR | 9µ SMF / 10km | |
| 100GBASE-LR4 | 9µ SMF / 10km | |
| 100GBASE-LRL4 | 9µ SMF / 2km | |
| 100GBASE-ERL4 | 9µ SMF / 40km | |
| Select QSFP100 Ports. Refer to Transceiver and Cable Guide for supported platforms | 100GBASE-ZR4 | 9µ SMF / 80km |
| 100G Copper QSFP | Type | Media/Reach |
| All QSFP100 Ports | 100GBASE-CR4 Twinax/Direct Attach 100G to 100G | Pre-terminated in 1m, 2m, 3m, 5m lengths |
| 100GBASE-CR4 to 4 x 25GBASE-CR 100G to 25G | Pre-terminated in 1m, 2m, 3m, 5m lengths | |
| 100GBASE-CR4 to 2 x 50GBASE-CR2 100G to 50G-2 | Pre-terminated in 1m, 2m, 3m, 5m lengths | |
| 200G Optical QSFP | Type | Media/Reach |
| All QSFP200 and QSFP-DD Ports | 200GBASE-SR4 | 50µ MMF / 70m (OM3), 100m (OM4) |
| 200GBASE-FR4 | 9µ SMF / 2km | |
| 200G Copper QSFP | Type | Media/Reach |
| All QSFP200 and QSFP-DD Ports | 200GBASE-CR4 Twinax/Direct Attach 200G to 200G | Pre-terminated in 1m, 2m, 3m lengths |
| 200GBASE-CR4 to 2 x 100GBASE-CR2 200G to 100G | Pre-terminated in 1m, 2m, 3m lengths | |
| 200GBASE-CR4 to 4 x 50GBASE-CR | Pre-terminated in 1m, 2m, 3m lengths | |
| 400G Optical OSFP | Type | Media/Reach |
| All OSFP Ports | 400GBASE-AOC | Pre-Terminated 1, 3, 5, 7, 10, 15, 20, 25, 30m lengths |
| 400GBASE-SR8 | 50µ MMF / 100m (OM3), 100m (OM4) | |
| 400GBASE-DR4 | 9µ SMF / 500m | |
| 400GBASE-XDR4 | 9µ SMF / 2km | |
| 400GBASE-PLR4 | 9µ SMF / 10km | |
| 400GBASE-FR4 | 9µ SMF / 2km | |
| 400GBASE-LR4 | 9µ SMF / 10km | |
| 400GBASE-2FR4 | 9µ SMF / 2km | |
| Select OSFP Ports. Refer to Transceiver and Cable Guide for supported platforms | 400GBASE-ZR | 9µ SMF / 120km |
| 400G Copper OSFP | Type | Media/Reach |
| 400GBASE-CR8 Twinax / Direct Attach 400G to 400G | Pre-terminated in 1m, 2m, 3m, lengths | |
| 400GBASE-CR8 to 2 x 200GBASE-CR4 400G to 200G | Pre-terminated in 1m, 2m, 3m, lengths | |
| 400GBASE-CR8 to 4 x 100GBASE-CR2 400G to 100G | Pre-terminated in 1m, 2m, 3m, lengths | |
| 400GBASE-CR8 to 8 x 50GBASE-CR 400G to 50G | Pre-terminated in 1m, 2m, 3m, lengths | |
| 400G Optical QSFP-DD | Type | Media/Reach |
| All QSFP-DD Ports | 400GBASE-AOC | Pre-Terminated 1, 3, 5, 7, 10, 15, 20, 25, 30m lengths |
| 400GBASE-SR8 | 50µ MMF / 100m (OM3), 100m (OM4) | |
| 400GBASE-DR4 | 9u SMF / 500m | |
| 400GBASE-XDR4 | 9u SMF / 2km | |
| 400GBASE-PLR4 | 9µ SMF / 10km | |
| 400GBASE-FR4 | 9u SMF / 2km | |
| 400GBASE-LR4 | 9µ SMF / 10km | |
| Select QSFP-DD Ports. Refer to Transceiver and Cable Guide for supported platforms | 400GBASE-ZR | 9µ SMF / 120km |
| 400G Copper QSFP-DD | Type | Media/Reach |
| 400GBASE-CR8 Twinax / Direct Attach 400G to 400G | Pre-terminated in 1m, 2m, 2.5m lengths | |
| 400GBASE-CR8 to 2 x 200GBASE-CR4 400G to 200G | Pre-terminated in 1m, 2m, 2.5m lengths | |
| 400GBASE-CR8 to 4 x 100GBASE-CR2 400G to 100G | Pre-terminated in 1m, 2m, 2.5m lengths | |
| 400GBASE-CR8 to 8 x 50GBASE-CR 400G to 50G | Pre-terminated in 1m, 2m, 2.5m lengths | |
| 800G Optical OSFP | Type | Media/Reach |
| All 800G OSFP ports | 800GBASE-AOC / 2x 400GBASE-AOC | Pre-Terminated 1, 3, 5, 7, 10, 15, 20, 25, 30m lengths |
| 2x 400GBASE-XDR4 | 9µ SMF / 2km | |
| 2x 400GBASE-PLR4 | 9µ SMF / 10km | |
| 2x 400GBASE-FR4 | 9µ SMF / 2km | |
| 2x 400GBASE-LR4 | 9µ SMF / 10km | |
| 800G Copper OSFP | Type | Media/Reach |
| All 800G OSFP ports | 800GBASE-CR8 / 2x 400GBASE-CR8 Twinax / Direct Attach | Pre-terminated in 1m and 2m lengths |
| 800G Optical QSFP-DD | Type | Media/Reach |
| All 800G QSFP-DD ports | 800GBASE-AOC / 2x 400GBASE-AOC | Pre-Terminated 1, 3, 5, 7, 10, 15, 20, 25, 30m lengths |
| 2x 400GBASE-XDR4 | 9µ SMF / 2km | |
| 2x 400GBASE-PLR4 | 9µ SMF / 10km | |
| 2x 400GBASE-FR4 | 9µ SMF / 2km | |
| 2x 400GBASE-LR4 | 9µ SMF / 10km | |
| 800G Copper QSFP-DD | Type | Media/Reach |
| All 800G QSFP-DD ports | 800GBASE-CR8 / 2x 400GBASE-CR8 Twinax / Direct Attach | Pre-terminated in 1 and 2m lengths |
