Supermicro Server Systeme

Supermicro Server Systeme

Mit einer ausgezeichneten Erfolgsbilanz hat Supermicro einen Ruf als ein wahrer MarktfĂźhrer in der High-End-Server / Storage-Industrie erworben. Supermicro bietet die herausragendste Produktlinie in der Branche, von einzelnen Atom™ und Dual Xeon® bis zu Quad Xeon® MP Systemen. Aufgrund ihres nachweislich hohen Qualitäts- und Leistungsniveaus sind SuperServer die erste Wahl fĂźr HPC-, Unternehmens-, Cloud-, Rechenzentrums-, embedded- und geschäftskritische Front-End-Serveranwendungen.

SuperServersÂŽ

SuperServer Vorteile:

  • Strenge Qualitätskontrolle
  • Beste Auswahl an High-End Servern - Itanium, Xeon und P4
  • Breiteste Auswahl an anwendungsoptimierten LĂśsungen, von High End Clustern bis MicroServern
  • Beste Leistung pro Watt, pro Quadratfuß und pro Dollar
  • Hervorragendes Produktdesign (alles unter einem Dach) in Silicon Valley
  • Konsequente Erstvermarktung
  • Beste Gesamtbetriebskosten (TCO)
  • Komponenten und Materialien hĂśchster Qualität
  • 3 Jahre Garantie und 24/7 Server Support / Global Services
  • Redfish API Support
  • Maximierte Leistung
  • Individuelle Konfiguration z.B als InfiniBand Cluster Node
  • Redundante Komponenten (eliminierte Ausfallzeiten des Systems)

Bitte wählen Sie die passende Größe des Racks:
Scalable Processors + C620 SuperServerSocket P - LGA 3467DP Xeon
1U XeonÂŽ Scalable Processors
Scalable Processors + C620 SuperServerSocket P - LGA 3467UP Xeon
1U XeonÂŽ Scalable Processors
C3000 Series System-on-Chip SuperServerUP AtomÂŽ
1U AtomÂŽ
E5-2600 v4/v3 + C612 SuperServerSocket R3 - LGA 2011DP Xeon
1U 64-bit XeonÂŽ SuperServer
E3-1500 v5 + C236 SuperServerSocket FCBGA 1440UP Xeon
1U Intel Xeon E3-1500 v5 family SuperServer
E3-1200 v6/v5 oder 7th/6th Gen. Core i3 + C236/C232 SuperServerSocket H4 - LGA 1151UP Xeon
1U Intel Xeon E3-1200 v6 family
E5-2600 + C600 based SuperServerSocket R - LGA 2011DP Xeon
1U XeonÂŽ E5-2600 / E5-2600 v2 Family
E5-2400 + C600 based SuperServerSocket B2 - LGA 1356DP Xeon
1U XeonÂŽ E5-2400 Series
E3-1200 v4/v3 + C220 based SuperServerSocket H3 - LGA 1150UP Xeon
1U Xeon® E3-1200 v4/v3 Familie, 4th gen. Core™ i3
7th/6th Gen. Core i7/i5/i3 + Q170 SuperServerSocket H4 - LGA 1151UP Core™
1U Intel 7th gen. Core™ i7/i5/i3 series
E5-2600/1600 v4/v3 + C612 SuperServerSocket R3 - LGA 2011UP Xeon
1U XeonÂŽ E5-2600/1600 v4/v3 Familie
Xeon D / Pentium D System-on-Chip SuperServerUP Xeon D
1U UP Xeon D / Pentium D
C2000 Series System-on-Chip SuperServerUP AtomÂŽ
1U AtomÂŽ C2000 Series
E5-2600 + C600 based SuperServerSocket R - LGA 2011UP Xeon
1U XeonÂŽ E5-2600 Series
S1200 Series System-on-Chip SuperServerCPU IntegratedUP Atom™
1U Atom™
QM77 SuperServerSocket: BGA1224UP Core
1U Core i7 / i5 Mobile ECC Processor
E5-4600 + C600 based SuperServerSocket R - LGA 2011MP Xeon
1U XeonÂŽ E5-4600 Series
5520/5500 (Tylersburg) SuperServerSocket 1366DP Xeon
1U XeonÂŽ 5600/5500 Series
5400 (Seaburg) SuperServerSocket 771DP Xeon
1U Quad/Dual-Core XeonÂŽ 5400/5300/5200/5100 Series
5100 (San Clemente) SuperServerSocket 771DP Xeon
1U Quad/Dual-Core XeonÂŽ 5400/5300/5200/5100 Series
5000X (Greencreek) SuperServerSocket 771DP Xeon
1U Quad/Dual-Core XeonÂŽ 5400/5300/5200/5100 Series
SuperServerStromversorgungCPUChipsatzSpeicherHDD
6015T-INFV /
6015T-INFB
1U Twin™ with
Infiniband
980 Watts2x Dual
(1333 FSB)
Intel 5000P
(Blackford)
2x 32GB FBD2x (2xSATA)
6015T-TV /
6015T-TB
1U Twin™
980 Watts2x Dual
(1333 FSB)
Intel 5000P
(Blackford)
2x 32GB FBD2x (2xSATA)
6015B-8+V /
6015B-8+B
700 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
64GB FBD4x U320 SCSI, ZCR
6015B-T+V /
6015B-T+B
700 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
64GB FBD4x SATA
6015X-3V /
6015X-3B
2U-in-1U!
700 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD3x SAS
6015X-8V /
6015X-8B
2U-in-1U!
700 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD3x U320 SCSI, ZCR
6015X-TV /
6015X-TB
2U-in-1U!
700 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD3x SATA
6015P-8 /
6015P-8B
700 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x U320 SCSI, ZCR
6015P-8R /
6015P-8RB
700 Watts
Redundant
Dual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x U320 SCSI, ZCR
6015P-T /
6015P-TB
700 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x SATA
6015P-TR /
6015P-TRB
700 Watts
Redundant
Dual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x SATA
6015B-URV /
6015B-URB
650 Watts RedundantDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x SAS **
Customizable
6015B-3RV /
6015B-3RB
650 Watts RedundantDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x SAS
6015B-NTRV /
6015B-NTRB
650 Watts RedundantDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x SATA
6015B-NTV /
6015B-NTB
560 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x SATA
6015B-3V /
6015B-3B
560 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x SAS
6015B-8V /
6015B-8B
560 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x U320 SCSI
6015B-TV /
6015B-TB
560 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x SATA
6015B-UV /
6015B-UB
560 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD4x SAS **
Customizable
6015B-Ni /
6015B-NiB
520 WattsDual
(1333 FSB)
Intel 5000P
(Blackford)
32GB FBD2x ATA100 oder 3x SATA
6015V-M3 /
6015V-M3B
520 WattsDual
(1333 FSB)
Intel 5000V
(Blackford VS)
24GB FBD4x SAS
6015V-MT /
6015V-MTB
520 WattsDual
(1333 FSB)
Intel 5000V
(Blackford VS)
24GB FBD4x SATA
6015V-T /
6015V-TB
520 WattsDual
(1333 FSB)
Intel 5000V
(Blackford VS)
24GB FBD2x SATA
6015V-MR /
6015V-MRB
520 WattsDual
(1333 FSB)
Intel 5000V
(Blackford VS)
24GB FBD1x ATA100 oder SATA
6015V-TLP /
6015V-TLPB
280 WattsDual (LV)
(1333 FSB)
Intel 5000V
(Blackford VS)
24GB FBD2x SATA
6015V-MRLP /
6015V-MRLPB
280 WattsDual (LV)
(1333 FSB)
Intel 5000V
(Blackford VS)
24GB FBD2x ATA100 oder SATA
** Available mit optional UIO Add-on Card from Supermicro
ICH9R/945GC (Lakeport) SuperServerCPU IntegratedUP Atom™
1U Atom™ D510/330/230 Series
C202/C204 (Cougar Point) SuperServerSocket 1155UP Xeon
1U Xeon® E3-1200 Family, 2nd gen. Core™ i3
X58 (Tylersburg-36S) SuperServerSocket 1366UP Xeon
1U Xeon® 5600/5500/3600/3500 Series, Core™ i7 Series
SuperServerStromversorgungCPUChipsatzSpeicherHDD
5016TI-TF920 Watts (Platinum)SingleIntel 3420 (Ibex Peak)2x 32GB DDR32x (2x SATA)
1016I-M6F560 WattsSingleIntel 3420 (Ibex Peak)32GB DDR38x SAS
5016I-URF450 Watts RedundantSingleIntel 3420 (Ibex Peak)32GB DDR34x SAS **
Customizable
1016I-UF330 Watts (Gold)SingleIntel 3420 (Ibex Peak)32GB DDR38x 2.5" SAS **
Customizable
5016I-NTF330 Watts (Gold)SingleIntel 3420 (Ibex Peak)32GB DDR34x SATA
5016I-M6F350 Watts (Gold)SingleIntel 3420 (Ibex Peak)32GB DDR34x SAS
5016I-MTHF350 WattsSingleIntel 3420 (Ibex Peak)32GB DDR34x SATA
5016I-MTF280 WattsSingleIntel 3420 (Ibex Peak)32GB DDR34x SATA
5016I-MT280 WattsSingleIntel 3400 (Ibex Peak)32GB DDR34x SATA
5016I-TF280 WattsSingleIntel 3420 (Ibex Peak)32GB DDR32x SATA
5016I-T280 WattsSingleIntel 3400 (Ibex Peak)32GB DDR32x SATA
5016I-MRHF350 WattsSingleIntel 3420 (Ibex Peak)32GB DDR31x SATA
5016I-MRF200 WattsSingleIntel 3420 (Ibex Peak)32GB DDR31x SATA
5016I-MR200 WattsSingleIntel 3400 (Ibex Peak)32GB DDR31x SATA
** Available mit optional UIO Add-on Card from Supermicro
X48 (Bearlake) SuperServerSocket 775UP Xeon
1U Quad-Core XeonÂŽ 3300/3200 Series, Dual-Core XeonÂŽ 3100/3000 Series
3210 (Bigby) SuperServerSocket 775UP Xeon
1U Quad-Core XeonÂŽ 3300/3200 Series, Dual-Core XeonÂŽ E3100/3000 Series
3000/3010 (Mukilteo-2/P) SuperServerSocket 775UP Xeon
1U Dual-Core XeonÂŽ 3200/3000 Series
E7520/7320 (Lindenhurst/VS) SuperServerSocket 604DP Xeon
1U 64-bit XeonÂŽ SuperServer
E7525 (Tumwater) SuperServerSocket 604DP Xeon
1U 64-bit XeonÂŽ SuperServer
E7520 (Lindenhurst) SuperServerSocket 479DP Xeon
1U Dual-core XeonÂŽ LV SuperServer
E7500/7501 (Plumas/533) SuperServerSocket 604DP Xeon
1U XeonÂŽ SuperServer
Serverworks (GC-LE/SL) SuperServerSocket 604DP Xeon
1U XeonÂŽ SuperServer
E7230/3000 (Mukilteo/-2P) SuperServerSocket 775UP PentiumÂŽ D
1U Dual-Core PentiumÂŽ D
E7221 (Copper River) & E845Socket 775 & 478UP PentiumÂŽ 4
U1 PentiumÂŽ 4 SuperServer
Scalable Processors + C620 SuperServerSocket P - LGA 3467DP Xeon
2U XeonÂŽ Scalable Processors
Scalable Processors + C620 SuperServerSocket P - LGA 3467UP Xeon
2U XeonÂŽ Scalable Processors
Scalable Processors + C620 SuperServerSocket P - LGA 3467MP Xeon
2U XeonÂŽ Scalable Processors
E5-2600 / C600 based SuperServerSocket R - LGA 2011DP Xeon
2U XeonÂŽ E5-2600 Series
E5-2600 / C600 based SuperServerSocket R - LGA 2011UP Xeon
2U XeonÂŽ E5-2600 Series
E5-2600 v4/v3 + C612 SuperServerSocket R3 - LGA 2011DP Xeon
2U XeonÂŽ E5-2600 v4/v3 Familie
E7-8800/4800/2800 v2 + C600 Series SuperServerSocket R1 - LGA 2011DP Xeon
2U XeonÂŽ E7-8800/4800/2800 v2 Family
E7-8800/4800 v4/v3 + C602J SuperServerSocket R1 - LGA 2011MP Xeon
2U XeonÂŽ E7-8800/4800 v4/v3 Familie
E5-2600/1600 v4/v3 + C612 SuperServerSocket R3 - LGA 2011UP Xeon
2U XeonÂŽ E5-2600/1600 v4/v3 Familie
E5-2400 / C600 based SuperServerSocket B2 - LGA 1356DP Xeon
2U XeonÂŽ E5-2400 v2 Series
E5-4600 v4/v3 + C600 SuperServerSocket R - LGA 2011MP Xeon
2U XeonÂŽ E5-4600 v4/v3 Familie
E5-4600 + C600 SuperServerSocket R - LGA 2011MP Xeon
2U XeonÂŽ E5-4600/E5-4600 v2 Family
5520/5500 (Tylersburg-EP) SuperServerSocket 1366DP Xeon
2U Quad/Dual-Core XeonÂŽ 5600/5500 Series
2U Twin3 SuperServerCPUs IntegratedUP Atom™
2U mit 8 Dual-Core Intel® Atom™ D525 processors
5400 (Seaburg) SuperServerSocket 771DP Xeon
2U Quad/Dual-Core XeonÂŽ 5400/5300/5200/5100 Series
5000P (Blackford) SuperServerSocket 771DP Xeon
2U Quad/Dual-Core XeonÂŽ 5400/5300/5200/5100 Series
E7520 (Lindenhurst) SuperServerSocket 604Prev. DP Xeon
2U 64-bit XeonÂŽ SuperServer
7500/7501 (Plumas/533) SuperServerSocket 603Prev. DP Xeon
2U 64-bit XeonÂŽ SuperServer
Serverworks (GC-LE) SuperServerSocket 604Prev. DP Xeon
2U 64-bit XeonÂŽ SuperServer
3420/3400 (Ibex Peak) SuperServerSocket 1156UP Xeon
2U XeonÂŽ X3400/L3400 Series
X58 (Tylersburg-36S) SuperServerSocket 1366UP Xeon
2U Xeon® 5600/5500/3600/3500 Series, Core™ i7 Series
3210 (Bigby) SuperServerSocket 775UP Xeon
2U Quad-Core XeonÂŽ 3300/3200 Series, Dual-Core XeonÂŽ E3100/3000 Series
3010 (Mukilteo-2P) SuperServerSocket 775UP Xeon
2U Quad/Dual-Core XeonÂŽ 3200/3000 Series
E7230/3010 (Mukilteo/-2P) SuperServerSocket 775UP PentiumÂŽ D
2U Dual-Core PentiumÂŽ D
E5-2600 v4/v3 + C612 SuperServerSocket R3 - LGA 2011DP Xeon
3U XeonÂŽ E5-2600 v4/v3 Familie
Xeon-D SuperServerSocket FCBGA 1667DP Xeon-D
3U XeonÂŽ D Family
E3-1200 v6/v5 + C236 SuperServerSocket H4 - LGA 1151UP Xeon
3U XeonÂŽ E3-1200 v6/v5 Family
E5-2400 + C600 SuperServerSocket B2 - LGA 1356DP Xeon
3U XeonÂŽ E5-2400 v2 Series
E5-2600 + C600 Series SuperServerSocket R - LGA 2011DP Xeon
3U XeonÂŽ E5-2600 / E5-2600 v2 Family
E3-1200 v3 + C220 / Atom C2750 SoC SuperServerSocket H3 - LGA 1150 / FCBGA 1283UP Xeon
3U XeonÂŽ E3-1200 v3 Familie / Atom C2750 Family
E5-2600/E5-2600 v2 + C600 SuperServerSocket R - LGA 2011UP Xeon
3U XeonÂŽ E5-2600 / E5-2600 v2 Family
C204 (Cougar Point) (MicroCloud™)Socket 1155UP Xeon
3U Xeon® E3-1200 Family, 2nd gen. Core™ i3
5520 (Tylersburg-36D) SuperServerSocket 1366DP Xeon
3U Quad/Dual-Core XeonÂŽ 5600/5500 Series
5000P (Blackford) SuperServerSocket 771DP Xeon
3U Quad/Dual-Core XeonÂŽ 5400/5300/5200/5100 Series
E7520 (Lindenhurst) SuperServerSocket 604Prev. DP Xeon
3U 64-bit XeonÂŽ SuperServer
7501 (Plumas 533) SuperServerSocket 603Prev. DP Xeon
3U 64-bit XeonÂŽ SuperServer
Scalable Processors + C620 Series FatTwin™ SuperServerSocket P - LGA 3647DP & UP Xeon
4U XeonÂŽ Scalable Processors
Scalable Processors + C620 Series SuperServerSocket P - LGA 3647DP Xeon
4U XeonÂŽ Scalable Processors
E5-2600 v4/v3 + C612 based FatTwin™ SuperServerSocket R3 - LGA 2011DP Xeon
4U XeonÂŽ E5-2600 v4/v3 Familie
E5-2600 v4/v3 + C612 based SuperServer SuperServerSocket R3 - LGA 2011UP Xeon
4U XeonÂŽ E5-2600 v4/v3 Familie
E7-8800/4800 v4/v3 + C602J SuperServerSocket R1 - LGA 2011MP Xeon
4U XeonÂŽ E7-8800/4800 v4/v3 Series
E5-2600/C602 based FatTwin™ SuperServerSocket R - LGA 2011DP Xeon
4U XeonÂŽ E5-2600 Series
E5-2600 / C602 Chipsatz based SuperServerSocket R - LGA 2011DP Xeon
4U XeonÂŽ E5-2600 Series
E5-4600 + C602 based SuperServerSocket R - LGA 2011MP Xeon
Tower/4U XeonÂŽ E5-4600 / E5-4600 v2 Family
5520 (Tylersburg-36D) SuperServerSocket 1366DP Xeon
4U Quad/Dual-Core XeonÂŽ 5600/5500 Series
5400 (Seaburg) SuperServerSocket 771DP Xeon
4U Quad/Dual-Core XeonÂŽ 5400/5300/5200/5100 Series
5100 (San Clemente) SuperServerSocket 771DP Xeon
4U Quad/Dual-Core XeonÂŽ 5400/5300/5200/5100 Series
5000X (Greencreek) SuperServerSocket 771DP Xeon
4U Quad/Dual-Core XeonÂŽ 5400/5300/5200/5100 Series
5000P (Blackford) SuperServerSocket 771DP Xeon
4U Quad/Dual-Core XeonÂŽ 5400/5300/5200/5100 Series
E7520 (Lindenhurst) SuperServerSocket 604DP Xeon
Tower/4U 64-bit XeonÂŽ SuperServer
E7525 (Tumwater) SuperServerSocket 604DP Xeon
Tower/4U 64-bit XeonÂŽ SuperServer
X58 (Tylersburg-36S) SuperServerSocket 1366UP Core™ i7
Tower Core™ i7 / Xeon® 5600/5500/3600/3500 SuperWorkstations
7500 (Boxboro-EX) SuperServerLGA 1567MP Xeon
5U 8-Way XeonÂŽ 7500 Series


SuperBladeÂŽ

SuperBlade Vorteile:

  • UnterstĂźtzt bis zu 205W TDP IntelÂŽ XeonÂŽ Skalierbare Prozessoren
  • UP, DP und 4-wege Blade Server
  • Bis zu 280 Knoten per Rack
  • Hot-swap U.2 NVMe, bis zu 8 Laufwerke per Blade Server
  • 100G EDR InfiniBand, 100G IntelÂŽ Omni-Path, und 25G/10G/1G Ethernet Switche
  • Redundante AC/DC Netzteile
  • Battery Backup Power (BBPÂŽ ) Module
  • Supermicro RSD und Redfish RESTful APIs ÜnterstĂźtzung
  • Free-air KĂźhlungs-Design mit niedrigster PUE

4U / 6U SuperBladeSuperblade SBI-4429P-T2NSuperblade SBI-6119P-C3NSuperblade SBI-6129P-C3NSuperblade SBI-6419P-C3NSuperblade SBI-6429P-C3N
Model NameSBI-4429P-T2NSBI-6119P-C3NSBI-6129P-C3NSBI-6419P-C3NSBI-6429P-C3N
Beschreibung4U / 2-Socket Blade6U / 1-Socket Blade6U / 2-Socket Blade6U / 1-Socket Blade6U / 2-Socket Blade
ProzessorenDual IntelÂŽ XeonÂŽ Scalable processors; 3 UPI bis zu 10.4GT/sSingle IntelÂŽ XeonÂŽ Scalable Processor, Dual UPI bis zu 10.4GT/sDual ntelÂŽ XeonÂŽ Scalable Processor, Dual UPI bis zu 10.4GT/sSingle IntelÂŽ XeonÂŽ Scalable processor, Dual UPI bis zu 10.4GT/s Dual IntelÂŽ XeonÂŽ Scalable Prozessor; 3 UPI bis zu 10.4GT/s
CPUs per 42U Rack280701409898
ChipsatzIntelÂŽ C622 ChipsatzIntelÂŽ C622 ChipsatzIntelÂŽ C622 ChipsatzIntelÂŽ C622 ChipsatzIntelÂŽ C622 Chipsatz
Speicher Unterstützung16 DIMM Slots; bis zu DDR4‑2666MHz12 DIMM Slots; bis zu DDR4‑2666MHz24 DIMM Slots; bis zu DDR4‑2666MHz12 DIMM Slots; bis zu DDR4‑2666MHz24 DIMM Slots; bis zu DDR4‑2666MHz
Max Speicher512GB VLP1.5TB Registered ECC RDIMM/LRDIMM3TB Registered ECC RDIMM/LRDIMM384GB VLP Registered ECC LRDIMM/RDIMM,768GB VLP Registered ECC LRDIMM/RDIMM
Erweiterung &
Hard Disk Drive
2 Hot-plug 2.5" SATA3 HDD/SSD/NVMe2 Hot-plug 2.5" NVMe + 1 Hot-plug SAS3/SATA3 Laufwerke oder 3 SAS3/SATA32 Hot-plug 2.5" NVMe + 1 Hot-plug SAS3/SATA3 Laufwerke oder 3 SAS3/SATA32 Hot-Plug 2.5" NVMe + 1 SAS3/SATA3 Laufwerk oder 3 SAS3/SATA3 und 4 internal M.22 Hot-Plug 2.5" NVMe + 1 SAS3/SATA3 Laufwerk oder 3 SAS3/SATA3 drives
InfiniBand/10GbE
Option
Dual 10G onboardDual 10G onboardDual 10G onboardDual 10G onboardDual 10G onboard
ManagementIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LAN
GraphicsAspeed AST2500 BMCAspeed AST2500 BMCAspeed AST2500 BMCAspeed AST2500 BMCAspeed AST2500 BMC
LED IndikatorenPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LED
Betriebstemperatur10°C - 35°C (50°F - 95°F)10°C - 35°C (50° bis 95°F)10°C - 35°C (50° bis 95°F)10°C - 35°C nicht kondensierend10° - 35°C (50° bis 95°F)
Maße6.5" x 1.2" x 23.5"9.75" x 1.75" x 23.5"9.75" x 1.75" x 23.5"9.75" x 1.2" x 23.5"9.75" x 1.2" x 23.5"
Superblade SBI-4129P-C2N/-T3N

SBI-4129P-C2N/-T3N

8U SuperBlade / 2-Socket Blade
  • Dual Socket P (LGA 3647) Support: IntelÂŽ XeonÂŽ Scalable Prozessor; 3 UPI bis zu 10.4GT/s
  • 200 CPUs per 42U Rack
  • IntelÂŽ C622 Chipsatz
  • 16 DIMM Slots; bis zu 2TB Registered ECC LRDIMM/RDIMM, bis zu DDR4‑2666MHz
  • Storage Options:
    • SBI-4129P-C2N – 2 Hot-plug 2.5" SAS3/SATA3 HDD/SSD/NVMe
    • SBI-4129P-T3N – 2 Hot-Plug 2.5" NVMe + 1 SATA3 drive
  • Broadcom 3108 (SBI-4129P-C2N)
  • Dual 10G onboard und High Speed Netzwerk Optionen (Ăźber 25G/100G EDR/Omni-Path Mezzanine Karte)
  • IPMI 2.0, KVM over IP, Virtual Media over LAN
  • Graphics: Aspeed AST2500 BMC
  • LED Indikatoren: Power, UID/KVM, Netzwerk, und Fehler LED
  • Maße: 6.5" x 1.75" x 23.5"
Superblade SBI-8149P-C4N/-T8N

SBI-8149P-C4N/-T8N

8U SuperBlade / 4-Socket Blade
  • Quad Socket P (LGA 3647) UnterstĂźtzung: IntelÂŽ XeonÂŽ Scalable Prozessor; 3 UPI bis zu 10.4GT/s
  • 200 CPUs per 42U Rack
  • IntelÂŽ C622 Chipsatz
  • 48 DIMM Slots; bis zu 6TB Registered ECC LRDIMM/RDIMM, bis zu DDR4‑2666MHz
  • Storage Options:
    • SBI-8149P-C4N – 4 Hot-plug 2.5" NVMe/SAS3/SATA3, 2 M.2 NVMe/SATA
    • SBI-8149P-T8N – 8 Hot-plug 2.5" NVMe oder 4 SATA3, 2 M.2 NVMe/SATA
  • Broadcom 3108, RAID 0, 1, 5, 10 Ăźber Mezzanine Karte (SBI-8149P-C4N)
  • 2x 10G LAN oder 100G EDR InfiniBand/Intel Omni-Path (Mezzanine Karte)
  • IPMI 2.0, KVM over IP, Virtual Media over LAN
  • Graphics: Aspeed AST2500 BMC
  • LED Indikatoren: Power, UID/KVM, Netzwerk, und Fehler LED
  • Maße: 13" x 1.75" x 23.5"
7U SuperBladeSuperblade SBI-7227R-T2Superblade SBI-7127RG/RG-ESuperblade SBI-7427R-SH/S2LSuperblade SBI-7127R-S6Superblade SBI-7427R-S3/T3
Model NameSBI-7227R-T2SBI-7127RG/RG-ESBI-7427R-SH/S2LSBI-7127R-S6SBI-7427R-S3/T3
BeschreibungTwinBladeÂŽGPU/Xeon Phi BladePCI-E BladeStorage BladeData Center Blade
ProzessorenZwei Eight/Six/Four-Core Xeon E5-2600 SeriesZwei Eight/Six/Four-Core Xeon E5-2600 SeriesZwei Eight/Six/Four-Core Xeon E5-2600 SeriesZwei Eight/Six/Four-Core Xeon E5-2600 SeriesZwei Eight/Six/Four-Core Xeon E5-2600 Series
CPUs per 42U Rack240120 (+120 GPU/MIC cards)168120168
ChipsatzIntel C602JIntel C602Intel C602JIntel C602JIntel C602J (S2)/C602 (T3)
Speicher UnterstĂźtzungRDIMM oder UDIMM DDR3 1600/1333/1066 in 8 slots/nodeRDIMM oder UDIMM DDR3 1333/1066/1600 in 8 slotsVLP RDIMM oder UDIMM DDR3 1600/1333/1066 in 16 slots+RDIMM oder UDIMM DDR3 1333/1066/1600 in 16 slotsLP RDIMM oder UDIMM DDR3 1600/1333/1066 in 16 slots
Max Speicher256GB(RDIMM) /64GB(UDIMM)256GB(RDIMM) /64GB(UDIMM)256GB(RDIMM) /64GB(UDIMM)512GB(RDIMM) /128GB(UDIMM)256GB(RDIMM) /64GB(UDIMM)
Erweiterung &
Hard Disk Drive
2x hot-plug 2.5” SATA3 hard disk drives/nodeRG-E Series:
- 2x Tesla Kepler K10/K20/K20X, GRID K1/K2, oder Xeon® Phi™
- 1x SSD
RG Series:
- 2x Tesla M2090/M2075
- 1x SATA DOM
SH Series:
- 1x PCI-E 3.0 x16 (FH/HL)
- 1x hot-plug 2.5" SAS2/SATA3
S2L Series:
- 1x PCI-E 3.0 x16 (HH/HL)
- 2x hot-plug 2.5" SAS2/SATA3
Sechs hot-plug 2.5” SAS2/SATA3 hard disk drivesDrei hot-plug 2.5” SAS2/SATA3 hard disk drives
Storage RAIDIntel PCH SATA RAID 0, 1N/ALSI 2308 controllerLSI 2208 HW RAID 0, 1,5,6,10,50 Battery Backup OptionLSI 2208 controller HW RAID 0,1,5 (S3), Intel PCH SATA RAID 0,1,5 (T3)
InfiniBand/10GbE
Option
4X FDR/QDR (40Gb) InfiniBand oder 10GbE mezzanine HCA /node4X QDR/FDR (40Gb) InfiniBand oder 10GbE mezzanine HCA4X QDR (40Gb) / DDR (20Gb) InfiniBand oder 10GbE mezzanine HCA4X FDR/QDR (40Gb) InfiniBand oder 10GbE mezzanine HCA4X QDR (40Gb) / DDR (20Gb) InfiniBand oder 10GbE mezzanine HCA
Ethernet InterfaceIntel i350 Dual-Port Gigabit Ethernet controllerIntel i350 Dual-Port Gigabit Ethernet controllerIntel i350 Dual-Port Gigabit Ethernet controllerIntel i350 Dual-Port Gigabit Ethernet controllerIntel i350 Dual-Port Gigabit Ethernet controller
ManagementIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LAN
GraphicsMatrox G200eWMatrox G200eWMatrox G200eWMatrox G200eWMatrox G200eW
LED IndikatorenPower LED, UID/KVM LED, Networking LED, Fehler LEDPower LED, UID/KVM LED, Networking LED, Fehler LEDPower LED, UID/KVM LED, Networking LED, Fehler LEDPower LED, UID/KVM LED, Networking LED, Fehler LEDPower LED, UID/KVM LED, Networking LED, Fehler LED
Betriebstemperatur10-35° C nicht kondensierend10-35° C nicht kondensierend10-35° C nicht kondensierend10-35° C nicht kondensierend10-35° C nicht kondensierend
Maße11.32” x 1.67” x 20.5”11.32” x 1.67” x 20.5”11.32” x 1.19” x 18.9”11.32” x 1.67” x 18.9”11.32” x 1.19” x 18.9”


7U SuperBladeSuperblade SBI-7126TGSuperblade SBI-7226T-T2Superblade SBA-7222G-T2Superblade SBA-7142G-T4
Model NameSBI-7126TG*EOL

SBI-7226T-T2*EOL
(zwei Knoten)
SBA-7222G-T2
(zwei Knoten)
SBA-7142G-T4

BeschreibungTwin BladeÂŽ
AMD Blade
4-Socket Blade
AMD Blade
ProzessorenZwei Sechs/Quad/Dual-Kern Xeon 5600/5500 Series pro KnotenZwei Sechs/Quad/Dual-Kern Xeon 5600/5500 Series pro KnotenZwei AMD Sixteen/Twelve/Eight- Core OpteronTM 6000 Series pro KnotenFour AMD Sixteen/Twelve/Eight- Core OpteronTM 6000 Series pro Knoten
CPUs per 42U Rack120 (+ 120 GPUs)240240240
ChipsatzIntel 5520 mit QPIIntel 5500 mit QPIAMD SR5650/SP5100AMD SR5650/SP5100
Speicher UnterstĂźtzungRDIMM oder UDIMM DDR3 1333/1066/800 in 6 slots pro KnotenRDIMM oder UDIMM DDR3 1333/1066/800 in 8 slots pro KnotenRDIMM oder UDIMM DDR3 1600/1333/1066 in 8 slots pro KnotenRDIMM oder UDIMM DDR3 1600/1333/1066 in 16 slots
Max Speicher96GB (RDIMM)/ 24GB (UDIMM)128GB(RDIMM)/ 32GB(UDIMM) pro Knoten128GB(RDIMM)/ 32GB(UDIMM) pro Knoten256GB(RDIMM)/ 64GB(UDIMM)
Erweiterung &
Hard Disk Drive
Supports 2 Tesla M2090/M2070/ M2070Q/M2050 1 SATA DOMZwei hot-plug 2.5” SATA hard disk drives pro KnotenZwei hot-plug 2.5” SATA hard disk drives pro KnotenFour hot-plug 2.5” SATA hard disk drives
Storage RAIDN/AIntel ICH10R SATA RAID 0, 1AMD SP5100 SATA RAID 0, 1AMD SP5100 SATA RAID 0, 1
InfiniBand/10GbE
Option
Dual 4X QDR InfiniBand oder 10GbE mezzanine HCA4X QDR (40Gb) InfiniBand oder 10GbE mezzanine HCA pro Knoten4X QDR (40Gb) InfiniBand oder 10GbE mezzanine HCA pro Knoten4X QDR (40Gb) InfiniBand oder 10GbE mezzanine HCA pro Knoten
Ethernet InterfaceIntel 82576 Dual-Port Gigabit Ethernet controller pro KnotenIntel 82576 Dual-Port Gigabit Ethernet controller pro KnotenIntel 82576 Dual-Port Gigabit Ethernet controller pro KnotenIntel 82576 Dual-Port Gigabit Ethernet controller pro Knoten
ManagementIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LAN
GraphicsMatrox G200eWMatrox G200eWMatrox G200eWMatrox G200eW
LED IndikatorenPower LED, UID/KVM LED, Netzwerk LED, Fehler LED pro KnotenPower LED, UID/KVM LED, Netzwerk LED, Fehler LED pro KnotenPower LED, UID/KVM LED, Netzwerk LED, Fehler LED pro KnotenPower LED, UID/KVM LED, Networking LED, Fehler LED
Betriebstemperatur10-35° C nicht kondensierend10-35° C nicht kondensierend10-35° C nicht kondensierend10-35° C nicht kondensierend
Maße11.32” x 1.67” x 20.5”11.32” x 1.67” x 20.5”11.32” x 1.67” x 20.5”11.32” x 1.67” x 20.5”


7U SuperBladeSuperblade SBI-7126T-SHSuperblade SBI-7426T-SHSuperblade SBI-7126T-S6Superblade SBI-7426T-S3/T3
Model NameSBI-7126T-SH*EOLSBI-7426T-SH*EOLSBI-7126T-S6*EOLSBI-7426T-S3/T3*EOL
ProzessorenZwei Sechs/Quad/Dual-Kern Xeon 5600/5500 SeriesZwei Sechs/Quad/Dual-Kern Xeon 5600/5500 SeriesZwei Sechs/Quad/Dual-Kern Xeon 5600/5500 SeriesZwei Sechs/Quad/Dual-Kern Xeon 5600/5500 Series
CPUs per 42U Rack120168120168
ChipsatzIntel 5520 mit QPIIntel 5500 mit QPIIntel 5520 mit QPIIntel 5520 mit QPI
Speicher UnterstĂźtzungRDIMM oder UDIMM DDR3 1333/1066/800 in 12 slotsRDIMM oder UDIMM DDR3 1333/1066/800 in 12 slots+RDIMM oder UDIMM DDR3 1333/1066/800 in 12 slotsRDIMM DDR3 1333/1066/800 in 12 slots+
Max Speicher192GB(RDIMM)/ 48GB(UDIMM)96GB(RDIMM)+192GB(RDIMM)/ 48GB(UDIMM)96GB (RDIMM)+
Erweiterung &
Hard Disk Drive
One PCI-E 2.0 x16 (FH/HL)Zwei hot-plug 2.5” SAS2/SATAOne PCI-E 2.0 x16 (FH/HL)Zwei hot-plug 2.5” SAS2/SATASechs hot-plug 2.5” SAS2/SATA hard disk drivesDrei hot-plug 2.5” SAS2/ SATA** hard disk drives
Storage RAIDLSI SAS 2008 RAID 0, 1***N/ALSI SAS 2008 RAID 0, 1, 10 Optional RAID 5LSI SAS 2008 RAID 0, 1 Optional RAID 5*
InfiniBand/10GbE
Option
4X QDR/DDR (40Gb/20Gb) InfiniBand oder 10GbE mezzanine HCA4X DDR (20Gb) InfiniBand oder 10GbE mezzanine HCA4X QDR/DDR (40Gb/20Gb) InfiniBand oder 10GbE mezzanine HCA4X DDR (20Gb) InfiniBand oder 10GbE mezzanine HCA
Ethernet InterfaceIntel 82576 Dual-Port Gigabit Ethernet controllerIntel 82576 Dual-Port Gigabit Ethernet controllerIntel 82576 Dual-Port Gigabit Ethernet controllerIntel 82576 Dual-Port Gigabit Ethernet controller
ManagementIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LAN
GraphicsMatrox G200eWMatrox G200eWMatrox G200eWMatrox G200eW
LED IndikatorenPower LED, UID/KVM LED, Networking LED, Fehler LEDPower LED, UID/KVM LED, Networking LED, Fehler LEDPower LED, UID/KVM LED, Networking LED, Fehler LEDPower LED, UID/KVM LED, Networking LED, Fehler LED
Betriebstemperatur10-35° C nicht kondensierend10-35° C nicht kondensierend10-35° C nicht kondensierend10-35° C nicht kondensierend
Maße11.32” x 1.67” x 18.9”11.32” x 1.19” x 18.9”11.32” x 1.67” x 18.9”11.32” x 1.19” x 18.9”


7U SuperBladeSuperblade SBI-7126T-T1LSuperblade SBI-7126T-T1ESuperblade SBI-7125C-S3/S3E/T3Superblade SBI-7425C-S3/S3E/T3Superblade SBI-7125W-S6
Model NameSBI-7126T-T1L*EOLSBI-7126T-T1E*EOLSBI-7125C-S3/S3E/T3*EOLSBI-7425C-S3/S3E/T3*EOLSBI-7125W-S6*EOL
ProzessorenZwei Sechs/Quad/Dual-Kern Xeon 5600/5500 SeriesZwei Sechs/Quad/Dual-Kern Xeon 5600/5500 SeriesZwei Sechs/Quad/Dual-Kern Xeon 5400/ 5300/5200/5100 SeriesZwei Sechs/Quad/Dual-Kern Xeon 5400/ 5300/5200/5100 SeriesZwei Sechs/Quad/Dual-Kern Xeon 5400/ 5300/5200/5100 Series
CPUs per 42U Rack120120120168120
ChipsatzIntel 5500 mit QPIIntel 5500 mit QPIIntel 5100Intel 5100Intel 5400 (1600MHz FSB)
Speicher UnterstĂźtzungRDIMM oder UDIMM DDR3 1333/1066/800 in 6 slotsRDIMM oder UDIMM DDR3 1333/1066/800 in 6 slotsECC Registered DDR2 667/533 in 6 slotsECC Registered DDR2 667/533 in 6 slots+Fully Buffered DIMM DDR2 800/667 in 8 DIMM Slots
Max Speicher96GB(RDIMM) /24GB(UDIMM)96GB(RDIMM) /24GB(UDIMM)48GB24GB+64GB
Erweiterung &
Hard Disk Drive
Zwei hot-plug 3.5” SATA hard disk drivesZwei hot-plug 3.5” SATA hard disk drivesDrei hot-plug 2.5” SAS/SATA** hard disk drivesDrei hot-plug 2.5” SAS2/SATA** hard disk drivesSechs hot-plug 2.5” SAS/SATA hard disk drives
Storage RAIDIntel ICH10R SATA RAID 0, 1Intel ICH10R SATA RAID 0, 1LSI SAS 1068E* RAID 0, 1 Optional RAID 5*LSI SAS 1068E* RAID 0, 1 Optional RAID 5*LSI SAS 1078 RAID 0, 1, 5, 6, 10, 50
InfiniBand/10GbE
Option
N/A4X QDR/DDR (40Gb/20Gb) InfiniBand oder 10GbE mezzanine HCA4X DDR (20Gb) InfiniBand oder 10GbE mezzanine HCA (nur S3E Version)4X DDR (20Gb) InfiniBand oder 10GbE mezzanine HCA (nur S3E Version)4X DDR (20Gb) InfiniBand oder 10GbE mezzanine HCA
Ethernet InterfaceIntel 82576 Dual-Port Gigabit Ethernet controllerIntel 82576 Dual-Port Gigabit Ethernet controllerIntel 82575EB Dual-Port Gigabit Ethernet controllerIntel 82575EB Dual-Port Gigabit Ethernet controllerIntel (ESB2) 82563EB Dual-Port Gigabit Ethernet controller
ManagementIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LAN
GraphicsMatrox G200eWMatrox G200eWATI ES1000 mit 32MB SDRAMATI ES1000 mit 32MB SDRAMATI ES1000 mit 16MB SDRAM
LED IndikatorenPower LED, UID/KVM LED, Networking LED, Fehler LEDPower LED, UID/KVM LED, Networking LED, Fehler LEDPower LED, UID/KVM LED, Networking LED, Fehler LEDPower LED, UID/KVM LED, Networking LED, Fehler LEDPower LED, UID/KVM LED, Networking LED, Fehler LED
Betriebstemperatur10-35° C nicht kondensierend10-35° C nicht kondensierend10-35° C nicht kondensierend10-35° C nicht kondensierend10-35° C nicht kondensierend
Maße11.32” x 1.67” x 18.9”11.32” x 1.67” x 18.9”11.32” x 1.67” x 18.9”11.32” x 1.19” x 18.9”11.32” x 1.67” x 18.9”


7U SuperBladeSuperblade SBI-7128R-C6N/-C6Superblade SBI-7128RG-X/-F/-F2Superblade SBI-7228R-T2F2/-T2FSuperblade SBI-7228R-T2XSuperblade SBI-7428R-T3N/-T3
Model NameSBI-7128R-C6N/-C6SBI-7128RG-X/-F/-F2SBI-7228R-T2F2/-T2FSBI-7228R-T2XSBI-7428R-T3N/-T3
ProzessorenDual IntelÂŽ XeonÂŽ E5-2600 v4/v3 Familie; QPI bis zu 9.6 GT/sDual IntelÂŽ XeonÂŽ E5-2600 v4/v3 Familie, QPI bis zu 9.6GT/sDual IntelÂŽ XeonÂŽ E5-2600 v4/v3 Familie; QPI bis zu 9.6 GT/sDual IntelÂŽ XeonÂŽ E5-2600 v4/v3 Familie; QPI bis zu 9.6 GT/sDual IntelÂŽ XeonÂŽ E5-2600 v4/v3 Familie; QPI bis zu 9.6GT/s
CPUs per 42U Rack120120240240168
ChipsatzIntelÂŽ C612 Express ChipsatzIntelÂŽ C612 ChipsatzIntelÂŽ C612 Express ChipsatzIntelÂŽ C612 Express ChipsatzIntelÂŽ C612 Express Chipsatz
Speicher Unterstützung16 DIMM Slots; bis zu 2TB ECC LRDIMM oder RDIMM DDR4‑24008 DIMM Slots; bis zu 1TB ECC LRDIMM oder RDIMM DDR4‑24008 DIMM Slots; bis zu 1TB ECC LRDIMM oder RDIMM DDR4‑24008 DIMM Slots; bis zu 1TB ECC LRDIMM oder RDIMM DDR4‑240016 VLP DIMM Slots
Max Speicher96TB (RDIMM)/(UDIMM)1TB ECC RDIMM/LRDIMM512GB ECC RDIMM/LRDIMM512GB ECC RDIMM/LRDIMM512GB VLP ECC RDIMM
Erweiterung &
Hard Disk Drive
3 Hot-plug NVMe + 3 Hot-swap SAS3 HDD Support (-C6N)
6 Hot-swap 2.5" SAS3 HDD Schächte; LSI 3108 (-C6)
1 SSD oder 2 SATA-DOM (Disk-On-Module) werden unterstßtzt2 Hot-swap 2.5" SATA3 HDD Schächte2 Hot-swap 2.5" SATA3 HDD Schächte3 Hot-plug NVMe Support via hybrid Ports (-T3N);
3 Hot-swap 2.5" SATA HDD Schächte (-T3)
NVMeBis zu 3---Bis zu 3
InfiniBand/10GbE
Option
4 QDR (40Gb) InfiniBand oder 10GbE mezzanine HCA1 FDR 56Gbps InfiniBand (-F) oder 2 FDR 56Gbps InfiniBand (-F2)Dual-Port (-T2F2) oder Single-port (-T2F) FDR (56Gb) InfiniBandOn-board dual 10Gb Ports4 QDR (40Gbps) / FDR (56Gbps) InfiniBand oder 10GbE mezzanine HCA
Ethernet InterfaceIntelÂŽ i350 Dual Port GbEDual Port 10G LAN (-X)IntelÂŽ i350 Dual Port GbEIntelÂŽ i350 Dual Port GbEIntelÂŽ i350 Dual Port GbE
ManagementIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LAN
GraphicsAspeed AST2400 BMCAspeed AST2400 BMCAspeed AST2400 BMCAspeed AST2400 BMC
LED IndikatorenPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LED
Betriebstemperatur10° - 35°C (50° bis 95°F)10°C - 35°C (50° bis 95°F)10°C - 35°C nicht kondensierend10°C - 35°C nicht kondensierend10° - 35°C (50° bis 95°F)
Maße11.32" x 1.67" x 20.5"11.32" x 1.67" x 20.5"11.32" x 1.67" x 20.5"11.32" x 1.67" x 20.5"11.32" x 1.19" x 18.9"


7U SuperBladeSuperblade SBI-7127R-SHSuperblade SBI-7127RG3Superblade SBI-7147R-S4FSuperblade SBI-7147R-S4XSuperblade SBI-7428R-C3N/-C3
Model NameSBI-7127R-SHSBI-7127RG3SBI-7147R-S4FSBI-7147R-S4XSBI-7428R-C3N/-C3
ProzessorenDual IntelÂŽ XeonÂŽ E5-2600 / E5-2600 v2 family; QPI bis zu 8.0GT/sDual IntelÂŽ XeonÂŽ E5-2600 / E5-2600 v2 family; QPI bis zu 8.0GT/s; 3 NVIDIA Kepler K20X/K40X SXMQuad IntelÂŽ XeonÂŽ E5-4600 / E5-4600 v2 family; QPI bis zu 8.0GT/sQuad IntelÂŽ XeonÂŽ E5-4600 / E5-4600 v2 family; QPI bis zu 8.0GT/sDual IntelÂŽ XeonÂŽ E5-2600 v4/v3 Familie; QPI bis zu 9.6GT/s
CPUs per 42U Rack120120240240168
ChipsatzIntelÂŽ C602 ChipsatzIntelÂŽ C602 ChipsatzIntelÂŽ C602J ChipsatzIntelÂŽ C602J ChipsatzIntelÂŽ C612 Express Chipsatz
Speicher UnterstĂźtzung16 DIMM Slots; bis zu DDR3-1866 Speicher8 DIMM Slots; bis zu DDR3-1866 Speicher16 DIMM Slots; bis zu DDR3-1866 Speicher16 DIMM Slots; bis zu DDR3-1866 Speicher16 VLP DIMM Slots
Max Speicher512GB512GB1TB1TB512GB VLP ECC RDIMM
Erweiterung &
Hard Disk Drive
2 Hot-swap 2.5" SAS2/SATA3 HDD Schächte;1 SATA DOM bis zu 64GB4 Hot-swap 2.5" SAS HDD Schächte; SAS2 via Broadcom 23084 Hot-swap 2.5" SAS HDD Schächte; SAS2 via Broadcom 23083 Hot-plug NVMe Support via hybrid Ports (-C3N);
3 Hot-swap 2.5" SAS3/SATA3 HDD Schächte (-C3)
NVMe----Bis zu 3
InfiniBand/10GbE
Option
4 QDR (40Gb) InfiniBand oder 10GbE Mezzanine HCAInfiniBand oder 10GbE OptionMellanox ConnectX-3 einzel-Port FDR 56Gbps InfiniBand, 40/10 GbE Support10GbE Support via Mellanox ConnectX-3 Pro EN Dual Port IC4 QDR (40Gbps) InfiniBand oder 10GbE Mezzanine HCA
Ethernet InterfaceIntelÂŽ i350 Dual Port GbEIntelÂŽ i350 Dual Port GbEIntelÂŽ i350 Dual Port GbEIntelÂŽ i350 Dual Port GbEIntelÂŽ i350 Dual Port GbE
ManagementIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LANIPMI 2.0, KVM over IP, Virtual Media over LAN
GraphicsMatrox G200eWMatrox G200eWMatrox G200eWMatrox G200eWAspeed AST2400 BMC
LED IndikatorenPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LEDPower, UID/KVM, Networking, und Fehler LED
Betriebstemperatur10° - 35°C (50° bis 95°F)10°C - 35°C (50°F bis 95°F)10°C - 35°C nicht kondensierend10°C - 35°C nicht kondensierend10° - 35°C (50° bis 95°F)
Maße11.32" x 1.19" x 18.9"11.32" x 1.67" x 20.5"11.32" x 1.67" x 20.5"11.32" x 1.67" x 20.5"11.32" x 1.19" x 18.9"

Fußnoten
* SAS und optionale RAID 5-Funktion nur fĂźr S3- und S3E-Version,
** SATA HDD nur fĂźr T3 Version,
*** BenĂśtigt Firmware Update, +VLP (very low-profile) Speicher Module
